Numerical Simulation of Multipoint Forming with Circular Die Pins in Hexagonal Packing

Abstract:

Multipoint forming (MPF) in flexible forming technology. from the previous research of multipoint forming, the configuration of the upper and lower punch matrices were configured in square packing. In this paper, model of multipoint forming configuration was developed and the numerical simulation was performed to investigate the influence of the proposed pins arrangement, hexagonal packing. The packing density in hexagonal arrangement is higher than in square one. The deformation process in multipoint forming with hexagonal packing is evaluated in terms of stress and strains distribution. The results demonstrated that forming tool with hexagonal packing is more efficient than pins arranged in square packing. But dimples and wrinkles as the typical defect of multipoint forming was inevitable consequences of discontinuous contact between the punches and workpiece, appeared. The dimpling phenomenon is more present in MPF with hexagonal packing than with square packing.

• Periodical: Applied Mechanics and Materials (Volume 493)
• Pages: 589-593
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.493.589
• Online since: January 2014
• Authors: Wardhani Rivai, Putu Suwarta, Budi Luwar Sanjoto, Husodo Nur, Subiyanto Hari
• Keywords: Hexagonal Packing, Multipoint Forming, Numerical Simulation, Packing Density

References

[1] Li. M. Z, Cai. Z. Y, Sui Z and Yan Q. G, Multi point forming technology for sheet metal, Journal of Material Processing Technology. 129 (2002) 333-338.

DOI: 10.1016/s0924-0136(02)00685-4

[2] Alfaidi, MF., Xiaoxing, Li, Nwir M.A., Numerical Simulation Application in Multi Point Forming, The 2nd International Conference Computer and Automation Engineering (2010) 502-504.

DOI: 10.1109/iccae.2010.5451628

[3] Liyong, Wang., Le Li, Computer Simulation of Thick Plate Multi-Point Forming Process, International Conference On Computer Design and Applications. (2010) 143-146.

DOI: 10.1109/iccda.2010.5541017

[4] Cai Zhong-Yi, Wang, SH, Xu XD, and Li MZ., Numerical Simulation for the Multi-Point Strecth Forming Process of Sheet Metal, Journal of Materials Processing Technology. (2009) 396-407.

DOI: 10.1016/j.jmatprotec.2008.02.010

[5] Walczyk D.F., Hardt D.E., Design and analysis of reconfigurable discrete dies for sheet metal forming, J. Manuf. Syst. 17 (1998) 436–454.

DOI: 10.1016/s0278-6125(99)80003-x

[6] ZhangQ., Dean T.A., Wang Z.R., Numerical Simulation of Deformation in Multi-Point Sandwich Forming, International Journal of Machine Tools & Manufacture. 46 (2005) 699-707.

DOI: 10.1016/j.ijmachtools.2005.07.034

[7] Steinhaus, H. Mathematical Snapshots, 3rd ed. New York: Dover, p.202, (1999).

[8] Chang, Hai-Chau; Wang, Lih-Chung., A Simple Proof of Thue's Theorem on Circle Packing, (2010).

[9] Paunoiu V, Cekan P, Gavan E., Nicoara D., Numerical Simulation in Reconfigurable Multipoint Forming, Journal of Material Processing Technology. 129 (2002) 333-338.

DOI: 10.1007/s12289-008-0021-4
