Design of Vibration Isolation Device for Ship Power Equipment and Investigation on its Dynamic Properties

Abstract:

Mechanical noise caused by power equipment vibration is the main source of underwater radiated noise of the ship, and vibration isolation and noise reduction of ship equipment has been widely concerned. Therefore,a vibration isolation system designed for four sets of auxiliary engine of ship cabin was investigated in the paper, aimed to further reveal the influence of various parameters including floating raft shell thickness, excitation source, and different ship hull and installation platform thickness on the vibration level difference of system. The results obtained from numerical analysis using MSC software and experiment indicate that one-dimensional spring element simplified can properly simulate the actual rubber vibration isolator on low frequency bands, and increasing thickness of flat, hull and platform can improve the effect of vibration isolation obviously.

• Periodical: Applied Mechanics and Materials (Volumes 496-500)
• Pages: 1129-1133
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.496-500.1129
• Online since: January 2014
• Authors: Yuan Yuan Fang, Guo Hong Zhang, Ya Fan Li, Peng Zhe Qi
• Keywords: Floating Raft, Power Equipment, Vibration Isolation, Vibration Level Difference

References

[1] LI D B, YAN L H. Modal synthesis method for vibration isolation design of massive rotating machines resiliently supported by an elastic structure [J]. Journal of Sound and Vibration, 2000, 231(1): 233-245.

DOI: 10.1006/jsvi.1999.2603

[2] HUI C K, NG C F. New floating floor design with optimum isolator location [J]. Journal of Sound and Vibration, 2007, 303: 221-238.

DOI: 10.1016/j.jsv.2007.01.011

[3] Zhanggui ZHONG. The whole raft power flow theory and experimental research [J]. Noise and Vibration Control, 2007, (3): 24-27.

[4] Feng Zhang. Acoustic design method and noise reduction performance analysis of space truss raft system [D]. China Ship Research Institute, 2012. (In Chinese).

[5] Guozhi Wang. Simulation and prediction of ship machinery noise excitation [J]. Journal of Jiangsu University of Science and Technology, 2011, 25(4): 315-319. (In Chinese).

[6] Jinming Song. The influence of isolator parameters and standing wave effect in high frequency on vibration isolation performance of floating raft [J]. The ship electrical technology, 2012, 32(12): 4-7. (In Chinese).
