Design and Validation of Sensor Balance for Propeller Experiment

Abstract:

This paper proposes a new two-component sensor balance to measure the thrust and torque of the propeller. Its principles of measuring force were derived and the procedures of balance measuring system were also provided according to the virtual instruments. The sensor balance was calibrated through the ground static calibration bench to verify its accuracy. And a ground static thrust experiment on a one-meter sized propeller model was carried out. By comparison, the experimental results of adopting the designed sensor balance basically tally with those of wind tunnel experiment, which proves that this sensor balance can be used in propeller experiments.

• Periodical: Applied Mechanics and Materials (Volumes 496-500)
• Pages: 652-656
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.496-500.652
• Online since: January 2014
• Authors: Jun Jiao*, Bi Feng Song, Yu Gang Zhang
• Keywords: Balance, Propeller Experiment, Sensor, Static Calibration, Virtual Instrument (VI)

References

[1] Liu, P. Q., Ma, R., Duan, Z. Z., & Ma, L. C. (2011). Ground wind tunnel test study of the propeller of stratospheric airships. Journal of Aerospace Power, 26(8), 1775–1781.

[2] Nie, Y., Wang, S., & Yang. Y. C. (2009). Comparative Analysis of Propeller Static Thrust Simulation and Experiment. Computer Simulation, 26(3), 103-107.

[3] Wang, L. G., Song, B. F., Shao, L. M., & Yuan, C. S. (2008). Flapping-wing Testing System Based on Virtual Instrument. Science Technology and Engineering, 8(5), 1224–1228.

[4] Morris, M., Callicoat, J., Arena A., Gaeta, R., & Jacob, J. (2013). Engine and Propeller Testing for Small to Mid-Size UAVs, AIAA-13-1134.

[5] Liu, P. Q. (2006). Theory and Application of Air Propellers, Beijing: Beihang University Publication, (2006).
