Safety Assessment and Strengthening for Long Span Double-Curved Arch Bridge with Design Drawing Lost

Abstract:

There are many old damaged double-curved arch bridges with design drawing lost serviced for more than 40 years are still used in West China. Based on the repair and improving the carrying capacity work of a damaged badly double-curved arch bridge whose design drawing is lost with main span of 41.0m constructed in 1962 in Sichuan province of China, health inspecting and safety assessment for this type bridge using non-destructive methods is studied. Then the strengthening design of filling concrete and enlarging the section method is proposed. High performance self-dense slight-expansion concrete and embedded bar techniques are applied in strengthening construction. After the strengthening work completed, the arch bridge is still in very good work condition experienced two devastating disasters of the 2008 Sichuan Wenchuan and the 2013 Sichuan Lushan earthquake, with the distance of bridge site to epicenter less than 100km, which proved the safety assessment and the strengthening design proposal are effective and feasible.

• Periodical: Applied Mechanics and Materials (Volumes 501-504)
• Pages: 1301-1304
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.501-504.1301
• Online since: January 2014
• Authors: Li Li*
• Keywords: Double-Curved Arch Bridge, Earthquake Resistance, Embedded Bar Technique, High-Performance Concrete (HPC), Safety Assessment, Strengthening

References

[1] Li Li, Wang zhenling, and Fu jinying: Disaster Advance. Vol5(2012), p.1111.

[2] Standard of Ministry of Communications of P.R.C. General Specifications for Design of Highway Bridges and Culverts(in Chinese). Beijing: China Communication Press, 1989. pp.3-15.

[3] Standard of Ministry of Communications of P.R.C. Identification Technique for Existing Highway Bridges(in Chinese). Beijing: China Communication Press, 1988. p.15.

[4] Wang Zhenling, Li Li. Structural Safety Evaluation and Strengthening of a Long Span Arch Bridge. In: Progress in Safety Science and Technology Volume 4, Proceedings of Asia Pacific Symposium on Safety 2005. Beijing: Science Press, 2005, p.542.

[5] Li Li, Wang zhenling: Journal of Xihua University(in Chinese). Vol. 29(2010), p.51.
