Experimental Study on Axial Tensile Performance of Low Volume Fraction of Ternary Hybrid Fiber Reinforced Concrete

Abstract:

In order to acquire axial tensile stress-strain curve of HFRC, specimens of equal cross-sections with embedded screw and pasted with carbon fiber cloth in corresponding length were tested on closed-loop electro-hydraulic servo testing machine which a subsidiary rigid frame was attached to. The effect of fiber volume, steel fiber slenderness ratio, steel fiber type and active admixture on the tensile properties of HFRC with low volume fraction was studied. The results indicate that when total volume proportion is less than 1% the first crack strength and ultimate tensile strength of HFRC can increase more than 15% and about 40% , respectively, the difference of effect of arched steel fiber and crimped steel fiber on the tensile behavior is small. The tensile behavior of HFRC is the best with a combination of slenderness ratio of 80 and 47.1kg/m³ arched steel fiber, 2.6kg/m³ macro-polypropylene fiber and1.0kg/m³ dura fiber and 10% .

• Periodical: Applied Mechanics and Materials (Volumes 511-512)
• Pages: 28-31
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.511-512.28
• Online since: February 2014
• Authors: Bo Ru Zhou, Dong Tao Xia*, Xiang Kun Liu
• Keywords: Hybrid Fiber, Splitting Strength, Stress-Strain Curve, Tensile Strength

References

[1] YAO Wu, WU Keru. Experimental conditions for the complete tension stress-strain curve of concrete[J]. Journal of Tongji University, 1996, (2): 142—145. (in Chinese).

[2] QU Fujin, ZHAO Guofan, HUANG Chengkui. Experimental study of tension stress-strain Curve of SIFCON in tension[J]. Journal of Dalian University of Technology, 1996, 36(6): 785—788. (in Chinese).

[3] HANG Rong, ZHAO Shun-bo, QU Fulai. Experimental study on the tensile performance of steel fiber reinforced concrete[J]. Chian civil engineering journal, 2006, 39(11): 63—67. (in Chinese).

[4] LU Yiyan, XIAO Huanxiong. An experimental method for examining the tensile behavior of steel fiber reinforced concrete[J]. Journal of Experimental Mechanics, 1999, 14(3): 259—266. (in Chinese).

[5] Reinhardt H W, Cornelissen A W, Hordijk D A. Tensile tests and failure analysis of concrete[J]. Journal of Structural Engineering, 1986, 112: 2462—2477.

DOI: 10.1061/(asce)0733-9445(1986)112:11(2462)

[6] XIA Dongtao, XU Shilang, XIA Guangzheng. Effect of hybrid fibers on Bending capacity of high-performance concrete deep beams[J]. Journal of Harbin institute of technology, 2010, 42(2): 313—316. (in Chinese).

[7] XIA Guangzheng, XIA Dongtao, XU Lihua, et al. Evaluation of ratio between splitting tensile strength and compressive strength for hybrid fiber reinforced HPC[J]. Journal of Chongqing Jianzhu University, 2007, 29(5): 103—106. (in Chinese).

[8] Standard test methods for fiber reinforced concrete(CECS 13: 2009)[S]. Beijing: China Association for Engineering Construction Standardization, 2010(in Chinese).
