The Image Information Recognition of Large Structures Based on CAD Model Characteristics

Abstract:

Because of the interference of the noise signals, the actual feature of objects cant be reflected clearly by photo which is measured by optical measurement. Thus, the database of feature of geometric model is established at the platform of Pro/E. Then the information selected will be extracted and exported, and compared to the photo which is gotten from the optical instrument. This can identify the information to prove the correctness when detecting objects photographed, which is used to adjust to the large structure.

• Periodical: Applied Mechanics and Materials (Volumes 511-512)
• Pages: 506-509
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.511-512.506
• Online since: February 2014
• Authors: Yu Kun Zhang, Qing Zhang*, Lei Zhao
• Keywords: Image Information Recognition, Large Structure, Model Characteristics

References

[1] Bingqiang Wang. Computer Applications Technology in ChineseVol. 37(2010), p.39.

[2] Jianfeng Yao. Machine Design and Research in Chinese Vol. 18 (2002), p.38.

[3] Shuhua and Yan Dai. Optical Technique in Chinese Vol. 29(2003), p.559.

[4] Chao Zhang. Systems Engineering and Electronics in Chinese Vol. 24(2002), p.126.

[5] Yue Liu. Computer Measurement & Control in Chinese Vol. 10(2002), p.363.

[6] Qifeng Fu. Transducer and Microsystem Technologies in Chinese Vol. 26(2007), p.28.

[7] Xiaodong Ruan. Computer Measurement & Control in Chinese Vol. 11(2000), p.571.

[8] Xiaoguang Gao. Flight Dynamics in Chinese Vol. 22 (2004), p.34.

[9] Qin Zhang: Rese. Advanced Science Letters in Chinese Vol. 4(2010), p.6.
