Design of Low Frequency Hydrophone Based on PVDF Piezoelectric Materials

Abstract:

In view of the existing of low frequency hydrophone in signal detection problems such as low sensitivity, frequency range is small, In this paper, application of PVDF piezoelectric film as sensitive material of low frequency hydrophone, use its advantages as fast response, high sensitivity, good mechanical properties, and so on [1], designed a kind of low frequency hydrophone, experiments are carried out to study the detection of low frequency signal. This paper introduces the structure, material and size of the hydrophone, and analyzes the experimental data. Experiments show that the sensor stability and high sensitivity, can effectively detect the low frequency acoustic wave in the water.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 3085-3089
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.3085
• Online since: February 2014
• Authors: Zhu En Chen*, Zhou Wan, Yi Yang Li, Hao Hua Liu, Xi Cun You
• Keywords: Hydrophone, Low Frequency, PVDF

References

[1] Ju Dianshu, Zhou Zhi, Ou Jinping. Study on strain-sensing of PVDF films[J]. Journal of Functional Materials, 2004(4): 450-456.

[2] Huang Jiannan. The way of backing material selection in PVDF bending disk hydrophone design[J]. Acoustics and Electronics Engineering, 1990, (2).

[3] Cao Bisheng. Design of Infrasonic Sensor based on PVDF: [ Master Thesis]. Kunming University of Science and Technology, (2012).

[4] Huang Jiannan. To improve sensitivity of bending disc hydrophone through reducing PVDF radius[J]. Acoustics and Electronics Engineering, 1989, (4).

[5] Wu Gang, Zhang Xiaoping. Design of Active Low-Pass Second Order Filter[J]. Ordnance Industry Automation, 2005, (4).
