Dynamic Reliability of Stochastic Truss Structures under Random Load

Abstract:

Aim at the dynamic reliability of stochastic truss structures under stationary random excitation. In consideration of the randomness of structural physical parameters and the geometric parameters and the random excitations were first transformed into sinusoidal ones in terms of the pseudo excitation method ( PEM) , that turned the joint-random problem into a single random problem for which only structural parameters remain random, and thus the analysis is greatly simplified. The mean value and the variance of the mean square value of the structural displacement and velocity were computed by using the theory of spectral analysis. And then the expressions of stochastic truss structural dynamic reliability were educed from the Poisson formula. Finally, the influence of the randomness of structural parameters on the structural dynamic reliability was analyzed by an example; the method of this paper was proved feasible and available comparing with the Monte Carlo method.

• Periodical: Applied Mechanics and Materials (Volume 525)
• Pages: 218-221
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.525.218
• Online since: February 2014
• Authors: Ming Liu*, Hui Mei Zhang
• Keywords: Pseudo Excitation Method, Random Factor Method, Random Load, Stochastic Parameter

References

[1] J.J. Chen, J.W. Che, H.A. Sun et al.: Probabilistic dynamic analysis of truss structures. Structural Engineering&Mechnics, 2002, 13(2): 231-239.

DOI: 10.12989/sem.2002.13.2.231

[2] J.J. Chen. Analysis of engineering structures response to random wind excitation. Computers&Structures, 1994, 51(6): 687-693.

DOI: 10.1016/s0045-7949(05)80007-0

[3] Jiahao Lin, Ping Yi. Stationary random responses of structures with stochastic parameters. Chinese journal of computational mechanics, 2001, 18(4): 402-407, in Chinese.

[4] Taibin Hu, Jianjun Chen, Xiaobing Wang. Displacement dynamic reliability analysis of stochastic rigid frames under stationary random excitation. Journal of Mechanical Strength, 2005, 27(5): 590-593, in Chinese.

[5] Taibin Hu. stochastic structure dynamic analysis and optimization design based on dynamic reliability. Xidian university, 2005: 61-67, in Chinese.

[6] Weiguang An , Weibing Zhu , Xinchi Yan. Application of Stochastic Finite Element Method to Analysis of uncertainties. Journal of Harbin Engineering University. 2002, 23(1): 132-135, in Chinese.
