Servo Drive Trajectory Design of Three-Axis Laser Processing System

Abstract:

Three-axis processing of laser inner engraving machine control system can carry on multi-axis linkage control. Furthermore, it ensures multi-axis of high feeding speed and trajectory control of high precision. This article introduces the design of laser inner engraving machine movement control system. The core is a digital integrator of linear interpolation algorithm to generate the desired trajectory and control XYZ axis linkage. Wide speed range of servo motor and position detector resolution is adequate to constitute a half-closed loop drive. With integral separation algorithm being introduced in the controller, the speed of numerical control system, track speed and positioning accuracy are guaranteed in order to achieve optimal specification for dynamic and static characteristics of the whole system.
