Optimal Design of Computerized Flat Knitting Machine Cam Curves Based on UG and ANSYS/LS-DYNA

Abstract:

By combining the industrial design software UG and finite element dynamic analysis software ANSYS/LS-DYNA, the paper respectively designs the non-linear knitting cams with polynomial curves, and simulates the loop-forming process in the interaction between the cams and needles. Based on comparative analyses, it’s thereby concluded that the polynomial curve has the best performance and is significantly superior to the cam curve composed of straight-lines and circular-arcs; the elements with higher stresses are located above the butt of needle jack and the joint of the jack and latch needle; and the polynomial curve is effective in lowering the maximum stress of the needle.

• Periodical: Applied Mechanics and Materials (Volume 529)
• Pages: 410-414
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.529.410
• Online since: June 2014
• Authors: Cang Zhao*, Guang Li Song, Lei Xu
• Keywords: ANSYS/LS-DYNA, Computerized Flat Knitting Machine, Kinematics, Non-Linear Knitting Cam, Optimal Design, UG

References

[1] KNAPTON J J F. The Dynamics of Weft-Knitting: A Mathematical Analysis[J]. Textile Research Journal, 1966(36): 706-714.

DOI: 10.1177/004051756603600804

[2] KNAPTON J J F, LAU T W Y. Design and dynamics of nonlinear cams for use in high-speed weft-knitting machines, part I: The theoretical dynamics of nonlinear cams [J]. Journal of the Textile Institute, 1978. 69 (n6): 161~168.

DOI: 10.1080/00405007808631436

[3] KNAPTON J J F, LAU T W Y. Design and dynamics of nonlinear cams for use in high-speed weft-knitting machines, part Ⅳ: The design and performance of nonlinear cams applied to a weft-knitting machine[J]. Journal of the Textile Institute, 1978, 69 (n6): 180-186.

DOI: 10.1080/00405007808631439

[4] KNAPTON J J F, LAU T W Y. Design and dynamics of nonlinear cams for use in high-speed weft-knitting machines, part Ⅴ: Theoretical and experimental comparisons[J]. Journal of the Textile Institute, 1978, 69 (n6): 187-193.

DOI: 10.1080/00405007808631440

[5] OLDHAM K, BURNS N D. Nonlinear cams for weft-knitting machines[J]. Journal of the Institute of Engineers (India), Part TE: Textile Engineering Division, 1989, 70(n1): 30－37.

DOI: 10.1080/00405008508631776

[6] Li Yanxia. Computerized optimal design of knitting cams [D]. Tianjin Polytechnic University, Tianjin, (2002).

[7] Jing Jianqiao, Ma Xiaojian. Dynamic characteristic analysis and optimal design of flat knitting machine cams [J]. Knitting Industries, 2006(3): 15-18.

[8] Jing Jianqiao, Ma Xiaojian. An analysis on the improvement of flat knitting machine cams[J]. Advanced Textile Technology, 2006(2): 1-5.

[9] Pan Youhua. Analysis and study on the looping mechanism of automatic computerized flat knitting machines [D]. Zhejiang Sci-Tech University, Zhejiang, (2008).

[10] Pan Youhua, Fang Yuan, Wang Hui. Movement track and technological design of computerized glove knitting machines[J]. Journal of Zhejiang Sci-Tech University, 2008(1): 34-37.

[11] Fang Yuan, Wang Hui, Tang Yan et al. Kinetic analysis of the loop elements of computerized hosiery knitting machines based on ANSYS/LS-DYNA [J]. Journal of Textile Research, 2009(7): 121-128.
