The Numerical Analysis of the Velocity and Pressure Distribution of the Oil Film in Heavy Hydrostatic Thrust Bearing

Abstract:

To study the velocity and pressure distribution of the oil film in a heavy hydrostatic thrust bearing, a mathematical model of the velocity is proposed and the finite volume method (FVM) has been used to simulate the flow field under different working conditions. Some pressure experiments were carried out and the results verified the correctness of the simulation. It is concluded that the pressure distribution varies small under different rotation speed when the surface load on the workbench is constant. But the velocity of the oil film is influenced greatly by the rotation speed. When the rotation speed of the workbench is as quick as enough, the velocity of the oil film on one radial side of the pad will be zero, that is to say the lubrication oil will be drained from the other three sides of the recess.

• Periodical: Applied Mechanics and Materials (Volumes 541-542)
• Pages: 658-662
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.541-542.658
• Online since: March 2014
• Authors: Jian Li*, Yuan Chen, Yang Chun Yu, Zhu Xin Tian, Yu Huang
• Keywords: FVM, Heavy Hydrostatic Thrust Bearing, Pressure Distribution, Velocity Distribution

References

[1] Lin, Jaw-Ren. Surface roughness effect on the dynamic stiffness and damping characteristics of compensated hydrostatic thrust bearings. International Journal of Machine Tools and Manufacture (2000).

DOI: 10.1016/s0890-6955(00)00012-2

[2] Heinrichson N., Fuerst A. and Santos I. F. The influence of injection pockets on the performance of tilting-pad thrust bearings. Journal of Tribology (2007).

DOI: 10.1115/1.2768609

[3] Novikov E. A., Shitikov I. A. and Maksimov V. A. Characteristics of hydrostatic thrust bearing. Khimicheskoe Neftegazovoe Mashinostroenie, (2004).

[4] MA Wen-qi, JIANG Jihai and ZHAO Keding. Research on temperature rise of hydrostatic thrust bearing under variable viscosity. China Mechanical Engineering, (2001).

[5] JIANG Jihai, MA Wen-qi and ZHAO Keding. Characteristic analysis of annular hydrostatic bearing based on variable viscosity. Journal of Harbin Institute of Technology. (2000).

[6] Chen G. H., Kang Y. and Chang Y. P. et al. Influences of recess geometry and restrictor dimension on flow patterns and pressure distribution of hydrostatic bearings. American Society of Mechanical Engineers, Proceedings. Ann Arbor, USA. (2007).

DOI: 10.1115/gt2007-28219

[7] Blackburn, John F., and J. Lowen Shearer, eds. Fluid power control. Technology Press of MIT. (1960).
