Design of Globoidal Indexing Cam Mechanism CAD System

Abstract:

With globoidal indexing cam mechanism as the object of study, this paper introduces its operating principle, analyzes and calculates its main motion parameters. On the basis of theoretical study, the paper using structured program design method and Visual Basic 6.0 as developing tool analyzes main function modules, such as system parameters input, law of motion, kinematics analysis and pressure angle check, etc. The paper develops globoidal indexing cam mechanism CAD system in simple operation and describes application method of the system and design examples.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 140-145
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.140
• Online since: March 2014
• Authors: Wei He*, Xue Ming He, Cheng Wang, Bin Deng
• Keywords: CAD System, Cam Mechanism, Function Module, Globoidal Indexing

References

[1] Guoxun Peng and Zhengyang Xiao. Design of Cam Mechanism of Automatic Machines [M]. Beijing: China Machine Press, (1990).

[2] Changqi Liu and Deao Zhang. Light Industrial Machinery [M]. Shaanxi: Shaanxi Science and Technology Express, (1996).

[3] Changqi Liu, Yeyang Mu and Xijing Cao. Design of Cam Mechanism [M]. Beijing: China Machine Press, (2005).

[4] Huijun Zou and Shiyu Dong. Modern Design of Cam Mechanism [M]. Shanghai: Shanghai Jiaotong University Press, (1991).

[5] Li Yang. Visual Basic Program Design Guide [M]. Beijing: China WaterPower Press, (2004).
