Radar Echo Parameter Estimation Using Sparse Time-Frequency Analysis Method

Abstract:

The echoes of pulse radar from maneuvering targets are amplitude modulation and frequency modulation (AM-FM) signal. At present, the methods of estimating parameters of AM-FM signal are time-frequency analysis method, empirical mode decomposition and empirical wavelet transform based adaptive data analysis methods. This paper takes the idea of intrinsic mode function in guessing the initial phase, and applies the newly developed sparse time-frequency analysis method in AM-FM signal parameter estimation. Simulation results show that the estimating performance of this method in AM-FM signal is good under different SNR and it has low computational cost, and this method is applicable in target acceleration and velocity estimation.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 2229-2233
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.2229
• Online since: March 2014
• Authors: Hao Chen*, Jun Hai Guo
• Keywords: Empirical Mode Decomposition (EMD), Instantaneous Freqeuency, Intial Phase, Radar Echo, Redundant Representation, Sparse Representation, Time-Frequency Analysis

References

[1] Kumar K AnooP, Arvind Manoj, Divakar K, RajagoPal R. A novel time-frequency approach for acceleration estimation from a single PRI". Fifth Int. Sym. Signal Proeessing and it, s applications, ISSPA 99, Brisbane Australia , 1999, p.531–534.

DOI: 10.1109/isspa.1999.815727

[2] Thayaparan T, YasotharanA. Anovel approach forthe Wigner distribution formulation of the optimum detection problem for a discrete-time chirp signal[J]. Defence Research Establishment Ottawa, 2001, 14(10): 23-27.

[3] WANG Min-sheng, Chan A K. Linear frequency-modulated signal detection using radon-ambiguity transform [J]. IEEE Trans Signal Processing, 1998, 46(3): 571-586.

DOI: 10.1109/78.661326

[4] Huang N E, Shen Z, Long S R, et al. The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis [J]. Proceedings of Royal Society of London, 1998(A454): 903-995.

DOI: 10.1098/rspa.1998.0193

[5] Wu Z, Huang N.E. Ensemble Empirical Mode Decomposition: a noise assisted data analysis method. Adv. Adapt. Data Anal., 2009, 1(1): 1-41.

DOI: 10.1142/s1793536909000047

[6] Cui Hua. New method for instantaneous frequency estimations of LFM signals [J]. Application Research of Computers, 2008, 25(8): 2532-2533, 2536.

[7] Zhen Haochuan, Shen Liran, Zhang Xiaolin. HHT-Based linear frequency modulated signal analysis and parameter estimation[J]. Applied Science and Technology, 2012, 39(3).

[8] I. Daubechies and J. Lu and H. T. Wu, Synchrosqueezed wavelet transforms: An empirical mode decomposition-like tool, Journal of Applied and Computational Harmonic Analysis, vol. 30, No. 2, p.243–261, (2011).

DOI: 10.1016/j.acha.2010.08.002

[9] J. Gilles. Empirical wavelet transform. Signal Processing, IEEE Transactions, vol. 61, pp.3999-4010, (2013).

DOI: 10.1109/tsp.2013.2265222

[10] Jia Shuyi, Wa Guohong ect. Acceleration and Velocity Estimation of Maneuvering Targets Based on Sparse and Redundant Representantions.

[11] T.Y. Hou and Z. Shi, Adaptive data analysis via sparse time-frequency representation[J]. Advances in Adaptive Data Analysis, vol. 2, p.1–28, (2011).

DOI: 10.1142/s1793536911000647

[12] T.Y. Hou and Z. Shi, Data-driven time-frequency analysis. Appl. Comput. Harmon. Anal. 35, p.284–308, (2013).
