Metrics on Software Structure Based on Structural Features in Software Network

Abstract:

According to the problem that traditional metric methods for software structure cannot reflect the structural features of software system on macro-view, the definition of Radiation Degree is presented based on software network that directed and weighted firstly, and the structural complexity of each node and the overall complexity of the system are measured by evaluating the outward Radiation Degree and inward Radiation Degree of the node. Secondly, because inward Radiation Degree and outward Radiation Degree are different reflection of structural features, Ratio of Radiation Cycle is presented to find the nodes have both high inward Radiation Degree and outward Radiation Degree. This method is detection for defects in software structure that can find the dangerous nodes in structure in time and provide guides during developing or maintaining of software system.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 3260-3263
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.3260
• Online since: March 2014
• Authors: Zheng Liu*, Qian Zhang, Hai Zhao
• Keywords: Metrics on Software, Software Network, Structural Complexity, Structural Defect, Structural Features

References

[1] Chidamber S R, Kemerer C F. A metrics suite for object oriented design, IEEE Transactions on Software Engineering, 20(6): 476-493, (1994).

DOI: 10.1109/32.295895

[2] Brito F, Abreu E. The MOOD metric set, Proc. of the ECOOP'95 Workshop on Metrics, Berlin, Germany, (1995).

[3] Liu J, He K Q, Ma Y T, et al. Scale Free in Software Metrics, Proc. of the 30th Annual International Computer Software and Applications Conference (Volume 1), 229-235, (2006).

[4] Liu J, He K Q, Peng R, et al. A Study on the Weight and Topology Correlation of Object Oriented Software Coupling Network, Proc. of the 1st International Conference on Complex Systems and Applications, 955-959, (2006).

[5] Ma Y T, He K Q, Du D H, et al. A Complexity Metrics Set for Large-scale Object-Oriented Software Systems, Proc. of the 6th International Conference on Computer and Information Technology, 189, (2005).

DOI: 10.1109/cit.2006.3

[6] Ma Y T, He K Q and Du D H. A qualitative method for measuring the structural complexity of software systems based on complex networks, Proc. of the 12th Asia-Pacific Software Engineering Conference, Taiwan, 257-263, (2005).

DOI: 10.1109/apsec.2005.14
