Numerical Simulation of Welding Residual Stress and its Creep Strain for Cr5Mo Steel Welded Joint

Abstract:

By the finite element analysis codes ABAQUS and the function of RESTART, a sequential coupling calculating program for creep based on welding residual stress has been developed by establishing the model of temperature field, residual field and creep analysis. The welding residual stress and creep of welded joint for Cr5Mo furnace tubes was simulated by the program. This method established the basis for calculating the effects of welding residual stress on the creep of welded joint. A creep comparison between the welded joint tubes with welding residual stress and with internal pressure was made in the paper. The results show that although the residual stress is greatly decreased due to the creep relaxation behavior at high temperature, the initial welding residual stress has a great influence on the tube creep. The research results provide a reference for strength design of high temperature components.

• Periodical: Applied Mechanics and Materials (Volumes 55-57)
• Pages: 41-46
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.55-57.41
• Online since: May 2011
• Authors: Ling Cheng, Zheng Nan Chen, Jian Gao
• Keywords: Cr5Mo Tubes, Creep Strain, Numerical Simulation, Weld Joint, Welding Residual Stress (WRS)

References

[1] J Q Zhang, H Y Zhao, et al. Research on the creep damage and interfacial failure of dissimilar metal welded joint between 10Cr9Mo1VNbN and 12Cr1MoV steel. Welding Research Abroad, 2005, 51 (1): 29-34.

[2] C Y Zhou, S T Tu,. A stochastic computation model for the creep damage of furnace tube. The International Journal of Pressure Vessels and Piping, 2001, 78 (9): 617-625.

DOI: 10.1016/s0308-0161(01)00075-8

[3] J M Gong, S T TU, et al. Research of welding effect of creep of high temperature furnace tubes . Journal of Materials Engineering 2000; (11): 9-12.

[4] J M Gong, S T TU, et al. Study on creep damage of weldments of HK40 furnace tubes based on creep damage mechanics . China Pressure Vessel Technology 2000; 17(4): 11-16.

[5] Noori, Soudabeh A. ，Price, John W. H. Case study of the use of API 581 on HK and HP material furnace tubes. Journal of Pressure Vessel Technology, Transactions of the ASME, 2005, 127 (1): 49－54.

DOI: 10.1115/1.1845475

[6] Ibarra, S., Konet, R.R. Life assessment of 1 1/4 Cr-1/2 Mo steel catalytic reformer furnace tubes using the MPC Omega method. Journal of Pressure Vessel Technology, Transactions of the ASME, 1995, 117 (1): 19－23.

DOI: 10.1115/1.2842084

[7] Eisinger, Frantisek L., Sullivan, Robert E. Avoiding thermoacoustic vibration in burner/furnace systems. Journal of Pressure Vessel Technology, Transactions of the ASME, 2002, 124 (4): 418－424.

DOI: 10.1115/1.1462623

[8] T.H. Hyde, W. Sun, J.A. Williams. Life estimation of pressurised pipe bends using steady-state creep reference rupture stresses. International Journal of Pressure Vessels and Piping, 2002, 79 (12): 799-805.

DOI: 10.1016/s0308-0161(02)00134-5

[9] T.H. Hyde, W. Sun, A. A. Becker. Creep crack growth in welds: a damage mechanics approach to predicting initiation and growth of circumferential cracks. International Journal of Pressure Vessels and Piping, 2001, 78 (11-12): 765-771.

DOI: 10.1016/s0308-0161(01)00088-6

[10] Hyde, T.H., Sun, W., Becker, A.A., Williams, J.A. Life prediction of repaired welds in a pressurised CrMoV pipe with incorporation of initial damage. International Journal of Pressure Vessels and Piping, 2004, 81 (1): 1-12.

DOI: 10.1016/j.ijpvp.2003.12.015

[11] R C Ying. Fusion welding theory and metal material welding [M]. Beijing: China Machine press, (2000).

[12] Dong P，Brust F W. Welding residual stress and effects on fracture in pressure vessel and piping components: a millennium review and beyond. Journal of Pressure Vessel Technology, 2000, 12 (8): 329－338.

DOI: 10.1115/1.556189

[13] H K S Inc. ABAQUS User's Manual (Version 6. 2) [M]. USA: Providence, RI, (2000).

[14] Fang X W et al. Mechanical material data manual [M]. Beijing: China Machine press, (1995).

[15] Zhao Haiyan, Lu Anli, et al. Implementation of numerical simulation technique in CAE of welding structures. China Mechanical Engineering, 2000, 11 (7): 732-734.

[16] Zhang G D, Zhou C Y. Finite element analysis of pipe discontinuous and continuous butt weld [J]. Transactions of the China Welding Institution, 2006, 27 (12): 85-88.
