Theoretic Analysis on Methods for One-Phase to Three-Phase Power Supply Transformation

Abstract:

The paper focuses on the review of methods of one-phase to three-phase transformation. Analysis of the demand of one-phase/three phase transformation is conducted. L-C splitting circuit, one-phase to three-phase transformation based on balance transformer, and one-phase to three-phase converter are three common methods of transformation, of which principle analysis and comparison of advantages and disadvantages have been conducted. This paper also discusses problems underlying the existing methods and proposes the possible future development.

• Periodical: Applied Mechanics and Materials (Volume 551)
• Pages: 562-568
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.551.562
• Online since: May 2014
• Authors: Guang Quan He*, Wen Rui Guo, Yong Qiang Zhu, Ya Feng Wen
• Keywords: Balance Transformer, Converter, L-C Phase Splitting, One-Phase to Three-Phase Transformation

References

[1] Zhengsheng Liu, Dunzhu Xia, Ling Weng. Single phase power supply research into split phase of three-phase power supply circuit [J]. University physics, 2000, 06: 25-28+45.

[2] Jihe Zhang, Zong Liu. The calculation method of L - C phase circuit component parameters [J]. Transactions of China Electrotechnical Society, 1996, 04: 58-61+35.

[3] Jihe Zhang, Zong Liu, Weisheng Fu. The nature of the relationship between the phase circuit parameter and load [J]. Journal of Dalian Railway Institute, 1995, 03: 35-40.

[4] Yangfan Ou, Youqing Zhou, Ziyong Guo. Current balance compensation method based on balance transformer [J]. Transactions of China Electrotechnical Society, 2007, 05: 53-57.

[5] Yangfan Ou, Youqing Zhou, Le Gao. Three phase- single phase power supply condition and parameter matching research based on balance transformer [J]. Proceedings of the CSEE, 2008, 13: 158-162.

[6] Yangfan Ou, Youqing Zhou, Qingquan Tang. A method based on balance transformer single-phase/three-phase power supply [J]. Transactions of China Electrotechnical Society, 2008, 09: 132-137.

[7] Guangye Liu, youqing Zhou, Jiangang Yao. Study of requirements and equivalent circuit of new balance transformer [J]. Proceedings of the CSEE, 1999, 19(04): 85-89.

[8] Li He, Mingxing Tian, Wenjun Tian, Yanju Liu. Y/>/balance of electric traction transformer application feasibility study [J]. Journal of Electric Power, 2010, 06: 463-466.

[9] Shousheng Jiang, Youqing Zhou, Guangye Liu. Operation characteristic analysis and model tests of Y/>/ connected balance transformer [J]. Proceedings of the CSEE, 2003, 23(4): 106-110.

[10] Hui Wang, Feng Xun, Zegen Wei. Three-phase voltage source PWM inverter double closed-loop control strategy research [J]. explosion-proof electric machine, 2007, 01: 11-14.

[11] Jianyuan Wang, Banduo Zhao, Yanchao Ji. Anlysis ona three-phase converter-inverter's work mode [J]. Proceeding of the EPSA, 2003, 15(1): 78-81.

[12] Xiaofeng Sun, Kun Wei, Weichang Wu. The three-phase inverter optimal control research [J]. Proceedings of the CSEE, 2004, 07: 172-176.

[13] Xianjin Song. Based on the dynamic model of the three-phase converter and space vector modulation [D]. Taiyuan University of Science and Technology, (2011).

[14] Jifei Du, Kexin Wei. The three-phase inverter induction voltage vector control method [J]. Transactions of China Electrotechnical Society, 2012, 11: 169-175.
