Research on Broadband Power Amplifier Adaptive Digital Pre-Distortion Based on FPGA Technology

Abstract:

In this paper, we use the adaptive function model to improve FPGA digital pre-distortion technique, design the adaptive pre-distortion function and algorithm, and adopt PC-CFR technique to process digital distortion problem in high order modulation, and obtain very good effect of digital signal processing. In order to verify the validity and reliability of PC-CFR technology, we use Agilent 89600 VSA software to exquisite power output signal before and after the broadband power amplifier pre-distortion. The results shows that before PC-CFR pre-distortion processing, phase difference of AM/PM reaches a maximum of 0.258, signal distortion is more serious; and after the PC-CFR pre-distortion processing, phase difference is only 0.021, the minimum is 0.005, which controls the distortion signal and improves the signal transmission quality. It provides technical reference to study the broadband power amplifier technology.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1761-1765
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1761
• Online since: May 2014
• Authors: Yu Shu Xiong*, Sheng Yi Ran
• Keywords: Agilent 89600, Broadband Power Amplifier, Digital Pre-Distortion Function, FPGA Technology, Pc-CFR Technology

References

[1] Xiao Jixue, Li Shixi, Cheng Zhi. Coarse signal processing of AC voltage smart sensor [J]. Journal of Xihua University (NATURAL SCIENCE EDITION), 2011(3): 34-39.

[2] Chen Shouqiang, Xiao Rongchuan, Xiao Jixue. Signal processing of power smart sensor [J]. Sensor and micro system, 2012(11): 45-49.

[3] Zhu Xiaoping, Tao Wei, Meng Chuiyi. Single wattmeter measurement method of power [J]. Journal of Shenyang Institute of Engineering (NATURAL SCIENCE EDITION), 2012, 3(3): 239-241.

[4] Shen Xiaofeng, Wang Jun, Zhu Wei, Feng Yuancheng. Power grid monitoring system based on virtual instrument technology [J]. Low voltage electrical apparatus, 2011, 21(351): 12-16.

[5] Li Binqin, Chen Weigen, Li Gang. Influence of harmonic wave on grid power metering device [J]. Power system technology, 2010, 36(531): 23-27.

[6] Xiao Zhiwen, Xie Shaobin, Chang Jian. Analysis of GPSAR subsurface target characteristics [J]. Modern radar, 2012, 31(5): 88-92.

[7] Zhang Qin, Wu Siliang, Li Hai. A new lookup table memory predistorter for power amplifier [J]. Acta electronica Sinica, 2012, 36(9): 1728-1732.

[8] Jiang Fei, Liu Zhong, Hu Wen et al. Analysis of continuous chaotic FM radar signals [J]. Journal of electronics & information technology, 2010, 32(3): 559-563.

[9] Liu Peiguo, Liu Jibin. Application of chaotic signal in UWB through wall imaging radar [J]. Journal of National University of Defense Technology, 2012, 29(3): 85-88.

[10] Xie Shaobin, Wang Anan, Xie Sheng. The performance of improved Tent chaotic FM radar signal anti multipath [J]. Modern radar, 2012, 34 (1): 25-29.

[11] Chen Bin, Zhou Zhengou, Liu Guanghu et al. Application of chaotic noise sources in the noise radar [J]. Modern radar, 2012, 30(5): 24-28.
