Gold Ball Wire Bonding Energy Transfer Mechanism and Experimental Studies

Abstract:

Because of the complexity of bonding process, the mechanism of bonding has been unable to agree. Accoding to previous research, a new bond energy transfer model is established: bond energy equals to energy caused by temperature rising and the friction energy.Then do experiment on bonding time, bonding stress and ultrasonic energy.Experimental results show that as the increase of process parameters, the bonding strength first increases then decrease, which consistent with the hypothesis.
