An Assessment of Carrying Capacity for Substructure of Offshore Modular Drilling Rig

Abstract:

Substructure of offshore modular drilling rig has complex loading. It is necessary that a 3D finite element analysis has been conducted by using finite element software for substructure. The distributions of integrated displacement and stress have been obtained. The results show that the axial strength and stiffness of the substructure are sufficient. The relevant evaluation methods were summarized and integrated into the finite element software, and the command flow program of post-processing is written. Through post-processing graphical display, the carrying capacity of substructure is presented. The results show that the carrying capacity of substructure can meet the requirements in the combination condition which contains the maximum rotary load and the maximum setback load. This research method can provide pertinent reference for carrying capacity assessment of steel structure, and have some practical significance for field operation.

• Periodical: Applied Mechanics and Materials (Volume 575)
• Pages: 521-525
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.575.521
• Online since: June 2014
• Authors: Feng Guan*, Chuan Xi Zhou, Jian Xu, Bo Zhou, Xian Zhong Yi
• Keywords: Assessment, CAD, Carrying Capacity, Finite Element Analysis (FEA), Offshore Drilling Rig, Substructure

References

[1] G.M. Barsan, and C.G. Chiorean: Computers and Structures. Vol. 72, No. 6 (1999), pp.699-711.

[2] J. Zhu: China Offshore Oil and Gas(Engineering). Vol. 12, No. 6 (2000), pp.44-46.

[3] S.S. Wang, H. Zhang, S.P. Dong, G.Z. Zhao and Y.Z. Zhang: Journal of Mechanical Strength. Vol. 25, No. 1(2003), pp.39-42.

[4] Quality Supervision & Inspection Center of Well Control Equipment for Petroleum Industry: The Specification for Grading and Evaluating the Loading Capacity on Derricks and Substructure of the Drilling Rig and Working Rig SY 6326-2012 (China Petroleum Industry Press, Beijing 2012).

[5] The Ministry of Construction of the People's Republic of China: Code for design of steel structures GB 50017-2003 (China Plans Press, Beijing 2003).

[6] H.L. Li, Y.X. Zhang: Coal Mine Machinery. Vol. 32, No. 1 (2011), pp.89-91.

[7] J.H. Zhang, Y. Liu: Machinery Design & Manufacture. No. 1 (2010), pp.25-26.

[8] General Administration of Quality Supervision, Inspection and Quarantine of P.R.C.: Petroleum and natural gas industries-Drilling and production equipment-Drilling and well-servicing structures GB/T 25428-2010(China Standards Press, Beijing 2010).

DOI: 10.3403/03175340

[9] Research Center of CNOOC Ltd.: For drilling rig on offshore petroleum platform Part 2: derrick and substructure Q/HS 2037. 2-2008(CNOOC, Tianjin 2008).
