Research of Laser Method for Measuring One Type of Ammunition Assembly Angle

Abstract:

In order to meet the measuring performance requirement of both high accuracy and large range when measuring the large-scale space angle formed by non-uniplanar lines quantitatively based on the engineering background of ammunition assembly angle test, we propose a measurement method that uses line structured laser as a common measurement reference and combined with vision inspection technique to achieve the measurement of large-scale space angle formed by non-uniplanar axes. Ammunition assembly angle have been measured accurately by using this method which provides a scientific approach for quality evaluation of that type of ammunition.

• Periodical: Applied Mechanics and Materials (Volume 577)
• Pages: 717-721
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.577.717
• Online since: July 2014
• Authors: Ai Guo Xu*, Zhi Bao Jiang, Li Xin Jia, Zhao He Ming
• Keywords: Common Measurement Reference, Large Scale, Laser Measurement, Non-Uniplanar Angle

References

[1] Du han-qin. Experimental techniques based radio fuze[M]. Beijing Weapons industry textbook editor chamber, 1987, P45-P67.

[2] Zang li-junj, Li xing-guo. Radio fuse circuit design principles[M]. Beijing National Defence Industry Press, 1987. P116-P147.

[3] LabVIEW User Manual For Windows. National Instruments Corporation, (1994).

[4] Xie ming-fang, Wang hong-yu. Virtual Instrument, Instrumentation Technology, 1998, (5), 43-45.

[5] MAXIM Popular IC Manual. Institute of Technology, Wuhan Liyuan SCM, 1994. 56-61.
