Application of Digital Speckle Correlation Method in Observation of Conrete Micro-Crack Damage

Abstract:

The splitting test for concrete specimens in four different dimensions were carried out in order to build the relative even micro-crack damage fields. The real-time whole-field displacements of concrete surface were measured omni-directionally by DSCM(Digital Speckle Correlation Method). Through analyzing the obtained experimental data, two kinds of micro-crack damage parameter are established :one is damage area based on the MCOD (Micro-Crack Opening Displacement) and another is damage variable based on the weighting-damping elastic modulus, which provides a new index and method for characterization of concrete micro-crack damage.

• Periodical: Applied Mechanics and Materials (Volumes 578-579)
• Pages: 1290-1294
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.578-579.1290
• Online since: July 2014
• Authors: Zhen Qiang Wang, Yan Liu*
• Keywords: Damage Parameter, Digital Speckle, Even Damage Field, Multidirectional Split

References

[1] Guanglong Fu and Xiaoyuan He. Study on Using Digital Speckle Correlation Method to Test the Full-field of Concrete Surface. [J]. Engineering and Test, Vol. 50, No. 1, March 2010(in Chinese).

[2] Huaiwen Wang, Yilan Kang and Donghui Fu. , Application of Digital Speckle Correlation Technique to Study Thin Film Fracture Problem. [J]. Journal of Yantai University, 2001 (2). (in Chinese).

[3] Huaiwen Wang, Caiping Liu, Yang Ju, Heping Xie, Qingquan Duan. Digital Speckle Correlation Method and Its Application under SEM. [J]. Journal of Experimental Mechanics, 2006(2). (in Chinese).

[4] Shaopeng Ma, Guanchang Jin, Yishan Pan. Deformation measurement method for rock materials based on natural speckle pattern. [J]. Chinese Journal of Rock Mechanics and Engineering, 2002, 21(6)：792-796(in Chinese).

[5] Shaopeng Ma. Development and application of digital speckle correlation method of failure masurement for rock materials[Ph.D. Thesis][D]. Beijing : T singhua University. 2003. (in Chinese).

[6] Huanqing Zhang, Qi Pan. Measurement of mocro-displacement based on digital speckle correlation method. [J]. Journal of Shandong University of Technology. Vol. 23, No. 1, Jan. 2009(in Chinese).

[7] Linlin Wang, Chen Tang. Pixel Searching Algorithm of Digital Image Speckle Correlation Based on Gradient Method. [J]. Electro-optic Technologh Application. Vol. 26, No. 3, June 2011 (in Chinese).
