Experimental Tests on Strengthened Masonry Vaults

Abstract:

This paper reports and discusses the results of experiments performed on masonry barrel vaults strengthened externally with a composite material. The vaults characterized by 125-mm thickness, 2000-mm internal span and 730-mm rise, were built of solid clay bricks and lime mortar. As a strengthening glass fiber grids or carbon fiber grids were used. They were embedded in a polymer-cement mortar at the vaults extrados. The main aim of presented research was to determine load-carrying capacity and examine failure modes of tested specimens. The results of performed tests show that observed failure modes depended on reinforcement ratio of strengthening layer. The specimen strengthened with one layer of glass fiber grid failed due to fibers rupture, whereas the vault strengthened with carbon fiber grid failed due to sliding along a mortar joint just above the abutment.

• Periodical: Applied Mechanics and Materials (Volumes 578-579)
• Pages: 1396-1399
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.578-579.1396
• Online since: July 2014
• Authors: Łukasz Hojdys, Piotr Krajewski*
• Keywords: Arches, Composite Material, Experimental Tests, Strengthening, TRM, Vaults

References

[1] M.R. Valluzzi, M. Valdemarca, C. Modena, Behavior of brick masonry vaults strengthened by FRP laminates, J. Compos. Constr. 5(3) (2001) 163-169.

DOI: 10.1061/(asce)1090-0268(2001)5:3(163)

[2] P. Foraboschi, Strengthening of masonry arches with Fiber-Reinforced Polymer strips, J. Compos. Constr. 8(3) (2004) 191-202.

DOI: 10.1061/(asce)1090-0268(2004)8:3(191)

[3] S. Briccoli Bati, S. Rovero, U. Tonietti, Experimental analysis on scale models of CFRP reinforced arches, 3rd National Congress Mechanics of Masonry Structures Strengthened with Composite Materials (MuRiCo 3), (2009) 140-145.

DOI: 10.1061/(asce)1090-0268(2007)11:1(33)

[4] D. Oliveira, I. Basilio, P. Lourenco, Experimental behavior of FRP strengthened masonry arches, J. Compos. Constr. 14(3) (2010) 312-322.

DOI: 10.1061/(asce)cc.1943-5614.0000086

[5] A. Borri, P. Casadei, G. Castori, J. Hammond, Strengthening of brick masonry arches with externally bonded steel reinforced composites, J. Compos. Constr. 13(6) (2009) 468-475.

DOI: 10.1061/(asce)cc.1943-5614.0000030

[6] Ł. Bednarz, A. Górski, J. Jasieńko, E. Rusiński, Simulations and analyses of arched brick structures, Autom. Constr. 20 (2011) 741-754.

DOI: 10.1016/j.autcon.2011.01.005

[7] Ł. Hojdys, Z. Janowski, Strengthening of masonry vaults with glass grids (in polish), Technical Transactions, 3-B (2011) 71-91.

[8] L. Garmendia, P. Larrinaga, D. García, I. Marcos, Textile-reinforced mortar as strengthening material for masonry arches, Int. J. Archit. Herit. 8(5) 627-648.

DOI: 10.1080/15583058.2012.704480

[9] Ł. Hojdys, P. Krajewski, Experimental tests on strengthened and unstrengthened masonry vault with backfill, 8th International Conference on Structural Analysis of Historical Constructions (SAHC 2012) (2012) 668-674.

[10] Ł. Hojdys, P. Krajewski, Behavior of masonry arches strengthened with TRM, 7th International Conference on Arch Bridges (ARCH'13) (2013) 739-746.

[11] Ł. Hojdys, T. Kamiński, P. Krajewski, Experimental and numerical simulations of collapse of masonry arches, 7th International Conference on Arch Bridges (ARCH'13) (2013) 715-722.
