Analysis of Structural and Non-Structural Problems by Coupling of Finite and Infinite Elements

Abstract:

The main idea of this paper is to present a smart numerical technique to solve structural and non-structural problems in which the domain of interest extends to large distance in one or more directions. The concerned typical problems may be the underground excavation (tunneling or mining operations) and some heat transfer problems (energy flow rate for construction panels). The proposed numerical technique is based on the coupling between the finite element method (M.E.F.) and the infinite element method (I.E.M.) in an attractive manner taking into consideration the advantages that both methods offer with respect to the near field and the far field (good accuracy and sensible reduction of equations to be solved). In this work, it should be noticed that the using of this numerical coupling technique, based on the infinite element ascent formulation, has introduced a more realistic and economic way to solve unbounded problems for which modeling and efficiency have been elegantly improved. The types of the iso-parametric finite elements used are respectively the eight-nodes (Q8) and the four-nodes (Q4) for the near field. However, for the far field the iso-parametric infinite elements used are the eight-nodes (Q8I) and the six-nodes (Q6I).

• Periodical: Applied Mechanics and Materials (Volumes 578-579)
• Pages: 445-455
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.578-579.445
• Online since: July 2014
• Authors: Mustapha Demidem*, Remdane Boutemeur, Abderrahim Bali, El-Hadi Benyoussef
• Keywords: Coupling, Deep Tunnels, Finite Element, Heat Transfer, Infinite Element

References

[1] M. Panet: Calcul des Tunnels par la Methode de Convergence-Confinement (Presses de l'Ecole Nationale des Ponts et Chaussées, Paris, 1995).

[2] G. Beer: Int. J. Num. Anal. Meth. Geo. Vol. 7 (1983), p.1.

[3] J. Schenck: Heat Transfer Engineering (Englewood Cliffs, Prentice Hall, Inc., 1959).

[4] J. Crank: Mathematics of diffusion (2nd Edition, Clarendon Press, Oxford, U.S.A., 1975).

[5] A. Bejan and A. Kraus: Heat Transfer Handbook (John Wily & Sons, Inc., U.S.A., 2003).

[6] G. Dhatt and G. Touzot: Une Présentation de la Méthode des Eléments Finis (Edition, Maloine S.A., Paris, 1981).

[7] K.J. Bathe: Finite Element Procedures in Engineering Analysis (Prentice Hall, Inc., U.S.A., 1982).

[8] O.C. Zienkiewicz and R.L. Taylor: The Finite Element Method (4th Edition, McGraw-Hill, U.K., 1989).

[9] I.M. Smith and D.V. Griffiths: Programming the Finite Element Method (John Wily & Sons, Ltd, U.K., 2006).

[10] M. Asghar Bhatti: Advanced Topics in Finite Element Analysis of Structures (John Wily & Sons, Inc., N.Y., 2006).

[11] K.W. Morton: Int. J. Num. Meth. Eng. Vol. 12 (1980), p.899.

[12] G.D. Smith: Numerical Solution of Partial Differential Equations (Oxford, U.S.A., 1985).

[13] J.J. Tuma: Handbook of Numerical Calculations in Engineering (McGraw-Hill, U.S.A., 1989).

[14] O.C. Zienkiewicz, C. Emons and P. Bettess: Int. J. Num. Meth. Eng. Vol. 19 (1983), p.393.

[15] P. Kumar: J. Str. Eng. Vol. 111, No. 11 (1985), p.2355.

[16] P. Bettess: Infinite Elements (Penshaw Press, U.K., 1992).

[17] T.G. Sitharam and I.V. Vijay Kumar: Geotechnical and Geological Engineering. Vol. 16 (1998), p.129.

[18] L. Demkowicz and J. Shen: Compt. Meth. Appl. Mech. Eng. Vol. 195 (2006), p.3572.

[19] M. Demidem: 1st International Conference on Sustainable Built Environment Infrastructures in Developing Countries, October (12-14), ENSET Oran, Algeria (2009).

[20] N. Vlachopoulos and M. S. Diederichs: Rock Mech. Eng. Vol. 42 (2009), p.131.

[21] P. Oreste: Am. J. of Appl. Sci. Vol. 6, No. 4 (2009), p.757.

[22] M. Demidem and A. Bali: 4ème Conférence Internationale sur les Mathématiques Appliquées et les Sciences de l'Ingénieur CIMASI'2002, (23-25) Octobre, Casablanca, Maroc (2002).

[23] M. Demidem: 7th International Congress, July (8-10), Dundee, Scotland, United Kingdom (2008).
