Thermal Simulation Analysis of Insulation of the New Heat-Insulation Bricks

Abstract:

Using the ANSYS thermal analysis module to do steady thermal analysis of given heat-insulating bricks. The results show that this kind of bricks can achieve better insulation in both sides; when the thermal conductivity of the heat insulating material in the hole space are less than 0.3 W/(m·K), the bricks can obtain the good insulation effect; the smaller the heat conductivity coefficients of the bricks materials and filling materials are, the better insulation bricks can achieve.

• Periodical: Applied Mechanics and Materials (Volumes 584-586)
• Pages: 1536-1540
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.584-586.1536
• Online since: July 2014
• Authors: Xiao Ping Feng*, Chun Ting Li, Jun Jie Wu
• Keywords: ANSYS, Heat Transfer Resistance, Heat-Insulating Bricks, Thermal Conductivity

References

[1] Yanhua Ye, Weimin Sun etc. Analysis of Concrete hollow block wall thermal insulation coefficient theory[J]. Insulation Materials and Building Energy Saving, 2002, 5: 27-29.

[2] Chen Liu. Thermal analysis techniques of ANSYS in the application of composite insulation block pass design[J]. Building Block & Block Construction, 2012, 05: 14-22.

[3] PENG Han-xiang YUAN Jian-wei XU Sheng. Study on the numerical simulation of the temperature field of the energy saving perforated concrete brick wall[J]. Shan Xi Structure, 2008, 34：23-24.

[4] Baoguo MA, Xiang HUANG, Song MU, Yingbing WANG, Dingbang WEI. Research on thermal simulation of fired perforated brick by ANSYS[J]. Brick title, 2009, 12: 14-16.
