Design and Fabrication of Flexible Three Link Manipulator for Pick and Place Application

Abstract:

Flexibility plays a key role in robot based applications, where the ability to perform complex tasks in semi structured or even unstructured environments is strategic.Most industrial robot operates inside a security fence which separates them from human workers, but not all. Flexibility, lightness in relation to the mass to be displaced and energy efficiency are acquiring increasing significance in automation. We can achieve higher performance in robots by optimizing the parameters like high-speed operation, lower energy consumption, lighter weight and safer operation. In this paper a pick and place robot is designed and developed to achieve effective automation with higher safety and with greater ease. The main objectives of designing this flexible manipulator are to reduce its mass and to minimize its vibrations in the end-effector, which enhances good accuracy in positioning.This can be achieved by bringing down the number of working components and jointswhich reduce various losses. The greater mass can be transferred from one place to another place with relatively lesser mass of flexible three link manipulator. The various problems were encountered and rectified during the design and fabrication of flexible three link manipulator for pick and place application.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 2134-2138
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.2134
• Online since: July 2014
• Authors: S.K. Naveen*, Kumaar Devaraj Rajesh, P. Pal Pandian
• Keywords: Flexibility, Manipulator, Stiffness

References

[1] M. E. Moran: Evolution of robotic arms, Journal of Robotic Surgery, vol. 1, no. 2, p.103–111 (May 2007).

[2] Francisco Valero, Vicente Mata, Antonio Besa: Trajectory planning in workspaces with obstacles taking into account the dynamic robot behaviour, Department of Mechanical Engineering, Universidad Polite´cnica de Valencia, Camino de Vera, 46022 Valencia, Spain.

DOI: 10.3866/pku.whxb20110501

[3] Santhosha Kumar Dwivedy, Peter Eberhard: Dynamic analysis of flexible manipulators, a literature review, Mechanism and Machine theory, published by Elsevier (March 2006).

DOI: 10.1016/j.mechmachtheory.2006.01.014

[4] A. De luca, F. Nicolo, G. Ulivi: Trajectory Tracking in Flexible Robot Arms.

[5] V.A. Utkin: Control of elastic multi-link manipulators based on the dynamic compensation method, Proceedings of the 1998 IEEE International Symposium on Circuits and Systems 6, p.594–597 (1998).

DOI: 10.1109/iscas.1998.705345

[6] R. Morales, V. Feliu, V. Jaramillo: Position control of very lightweight single-link flexible arms with large payload variations by using disturbance observers, Department of Electric, Electronics and Automation, University of Castilla-La Mancha, 13071, Ciudad Real, Spain.

DOI: 10.1016/j.robot.2011.11.016

[7] Ashitava Ghosal: Robotics Fundamental Concepts and Analysis, Oxford University Press, ISBN-13: 978-0-19-567391-3, p.315.
