Input Shaping for Feedforward Control of a Flexible Polymethyl Methacrylate Beam Manipulator

Abstract:

The objective of this research work is to model a dynamical system that can undergo flexible deformations along with the general rigid-body motions. For the system to be able to provide precise outputs when excited by an input, the modal shapes need to be examined and a suitable control strategy is required to make the manipulator adapt to a particular use. The input shaping parameters have been analyzed for specific modes of vibrations. The model uses a Gaussian input torque and power spectral density plots are developed with suitable sampling frequency to show the variation of PSD for the modes of vibration under consideration, thereby providing an insight into the shaping parameters of the Gaussian input.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 2160-2164
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.2160
• Online since: July 2014
• Authors: Bajwa Roodra Pratap Singh*, P.V. Manivannan
• Keywords: Flexible Link, Input Shaping, Modes of Vibration, Open Loop Control, Vibration Suppression

References

[1] A. Bannerjee, B. Bhattacharya, and A.K. Mallik (2011), Forward and Inverse Analyses of an SMA Actuated Compliant Link, Journal of Mechanisms and Robotics, Vol. 3, 021003, pp.1-10.

DOI: 10.1115/1.4003528

[2] Larry L. Howell (2001), Compliant Mechanisms, John Wiley and Sons.

[3] M.O. Tokhi, A.K.M. Azad (2008), Flexible Robot Manipulators: Modelling, Simulation and Control, IET, London, UK.

[4] Meirovitch, L. (1967), Analytical Methods in Vibrations, Macmillan, New York.

[5] Moallem, M., Patel, R.V., and Khorasani, K., (2002), Nonlinear Tip-Position Control of a flexible-Link Manipulator. Theory and Experiments, Automatica, Vol. 37, No. 11, 1825-1834.

DOI: 10.1016/s0005-1098(01)00130-3

[6] James M. Hyde and Warren P. Seering (1991), Using Input Command Pre-Shaping to suppress Multiple Mode Vibration, Proceedings of the 1991 IEEE International Conference on Robotics and Automation, Sacramento, CA- April (1991).

DOI: 10.1109/robot.1991.132020

[7] Singhose, W., Banerjee, A. and Seering, W. (1997), Slewing Flexible Spacecraft with Deflection-Limiting Input Shaping, Journal of Guidance, Control, and Dynamics, Vol. 20(2), pp.291-298.

DOI: 10.2514/2.4036

[8] F. Boyer, N. Glandais, and W. Khalil, (2002), Flexible Multibody Dynamics Based on a Non-Linear Euler-Bernoulli Kinematics, International Journal for Numerical Methods in Engineering, Vol. 54, No. 1, 27-59.

DOI: 10.1002/nme.414

[9] Francois Axisa, Philippe Trompette (2005), Modelling of Mechanical Systems: Structural Elements, Volume 2, Butterworth –Heinemann.
