Investigation on Interlaminar Shear Stresses in Laminated Composite Plates under Thermal and Mechanical Loading

Abstract:

In this study the combined effect of thermal environment and mechanical loadings on the interlaminar shear stresses of both moderately thin and thick composite laminated plates are numerically analyzed. The finite element modeling of laminated composite plates and analysis of interlaminar stresses are performed using the commercially available software package MSC NASTRAN/PATRAN. The validity of the present finite element analysis is demonstrated by comparing the interlaminar stresses developed due to mechanical loadings derived using the present FEM with those of available literature. Various parametric studies are also performed to investigate the effect of thermal environment on interlaminar stresses generated in asymmetric cross-ply composite laminated plates of different length to thickness ratios (L/H) and boundary conditions with identical mechanical loadings. It is observed that the elevated thermal environment under identical mechanical loading lead to higher interlaminar shear stresses varying with length to depth ratio and boundary conditions in asymmetric cross-ply laminated composite plates.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 451-455
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.451
• Online since: July 2014
• Authors: Nagaraj Murugesan*, R. Vasudevan
• Keywords: Asymmetric Cross-Ply Laminated Composite Plate, Finite Element Analysis (FEA), Interlaminar Shear, Orthotropic Materials, Thermal Environment

References

[1] M. Tahani: Analysis of laminated composite beams using layerwise displacement theories. Composite Structures Vol. 79 (2007), p.535.

DOI: 10.1016/j.compstruct.2006.02.019

[2] H. Matsunaga: Interlaminar stress analysis of laminated composite and sandwich circular arches subjected to thermal/mechanical loading. Composite Structures Vol. 60 (2003), p.345.

DOI: 10.1016/s0263-8223(02)00340-9

[3] N.J. Pagano: Exact solutions for composite laminates in cylindrical bending. Journal of Composite Materials Vol. 3 (1969), p.398.

DOI: 10.1177/002199836900300304

[4] N.J. Salamon: Interlaminar stresses in a layered composite Laminate in bending. Fibre Science and Technology Vol. 11 (1978), p.305.

DOI: 10.1016/0015-0568(78)90020-9

[5] C. Kassapoglou: Determination of Interlaminar Stresses in Composite Laminates under Combined Loads. Journal of Reinforced Plastics and Composites Vol. 9 (1990), p.33.

DOI: 10.1177/073168449000900103

[6] C.Y. Lee and D. Liu: An interlaminar stress continuity theory for laminated composite analysis. Computers & Structures Vol. 42 (1992), p.69.

DOI: 10.1016/0045-7949(92)90537-a

[7] H. Matsunaga: Interlaminar stress analysis of laminated composite beams according to global higher-order deformation theories. Composite Structures Vol. 55 (2002), p.105.

DOI: 10.1016/s0263-8223(01)00134-9

[8] J. Oh and M. Cho: A finite element based on cubic zig-zag plate theory for the prediction of thermo-electric-mechanical behaviours. International Journal of Solids and Structures Vol. 41 (2004), p.1357.

DOI: 10.1016/j.ijsolstr.2003.10.019

[9] H. Wu and X. Yan: Interlaminar stress modeling of composite laminates with finite element method. Journal of Reinforced Plastics and Composites Vol. 24 (2005), p.130.

DOI: 10.1177/0731684405043553

[10] M. Aydogdu: Thermal buckling analysis of cross-ply laminated composite beams with general boundary conditions. Composites Science and Technology Vol. 7 (2007), p.1096.

DOI: 10.1016/j.compscitech.2006.05.021

[11] T.S. Plagianakos and D.A. Saravanos: Higher-order layerwise laminate theory for the prediction of interlaminar shear stresses in thick composite and sandwich composite plates. Composite Structures Vol. 87 (2009), p.23.

DOI: 10.1016/j.compstruct.2007.12.002

[12] P. Vidal and O. Polit: A refined sine-based finite element with transverse normal deformation for the analysis of laminated beams under thermo mechanical loads. Journal of Mechanics of Materials and Structures Vol. 4 (2009), p.1127.

DOI: 10.2140/jomms.2009.4.1127

[13] M. Shariyat: A generalized high-order global–local plate theory for nonlinear bending and buckling analyses of imperfect sandwich plates subjected to thermo-mechanical loads. Composite Structures Vol. 92 (2010), p.130.

DOI: 10.1016/j.compstruct.2009.07.007

[14] D. Gayen and T. Roy: Hygro-Thermal Effects on Stress Analysis of Tapered Laminated Composite Beam. International Journal of Composite Materials Vol. 3 (2013), p.46.
