Small Punch Creep Testing Technique for Remnant Life Assessment

Abstract:

Small punch creep (SPC) testing technique is a material non-intensive testing technique for evaluating creep behavior of materials using miniature specimens. It can be used for remnant life assessment (RLA) studies on components in service, by scooping out limited material for testing without impairing the strength of component. In order to ensure the reliability of use of SPC technique for RLA, it is necessary to establish sound database on SPC properties of the material before putting into service. In this investigation, SPC technique was used to evaluate creep properties of 316LN stainless steel using specimens of size 10 x 10 x 0.5 mm. SPC tests were conducted in load controlled mode at 923 K and at various loads. SPC curves clearly exhibited primary, secondary and tertiary creep stages. The minimum deflection rate increased and rupture life decreased with an increase in applied load. Like in conventional creep test results, the minimum deflection rate obeyed Norton’s power law and Monkman-Grant relationship. SPC test was correlated with corresponding conventional creep test. Good correlation was established between creep rupture life values evaluated from SPC tests and conventional creep tests.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 739-743
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.739
• Online since: July 2014
• Authors: J. Ganesh Kumar*, K. Laha, M.D. Mathew
• Keywords: 316LN SS, RLA, Small Punch Creep

References

[1] F. Di Persio, G.C. Stratford, R.C. Hurst, Validation of the small punch test as a method for assessing ageing of a V modified low alloy steel, in: J. Veivo, P. Auerkari (Eds. ), Proc. of Baltica VI conference, Vol. 2, VTT symposium 234, Helsinki, 2004, pp.523-525.

[2] S. Tettamanti, R. Crudeli, A procedure for high temperature plant components life evaluation: Small punch creep test methodology, in: V. Bicego, A. Nitta, J.W.H. Price and R. Viswanathan (Eds. ), Proc. of Intl. symposium on case histories on structural integrity and failures in industry, Milan, Italy (1999).

[3] B. Ule, T. Sustar, F. Dobes, K. Milicka, V. Bicego, S. Tettamanti, K. Maile, C. Schwarzkopf, M.P. Whelan, R.H. Kozlowski, J. Klaput, Small punch test method assessment for the determination of the residual creep life of service exposed components: outcomes from an interlaboratory exercise, Nucl. Engg. Des. 192 (1999).

DOI: 10.1080/135993799349036

[4] S. Komazaki, T. Sugimoto, Y. Hasegawa, Y. Kohno, Damage evaluation of a welded joint in a long term service exposed boiler by using a small punch creep test, ISIJ Intl. 47 (2007) 1228-1233.

DOI: 10.2355/isijinternational.47.1228

[5] CEN Workshop Agreement, CWA 15627: 2006 E, Brussels, Belgium, (2006).

[6] M.D. Mathew, J. Ganesh Kumar, V. Ganesan, K. Laha, Small punch creep studies for optimization of nitrogen content in 316LN SS for enhanced creep resistance, Metall. Mater. Trans. 45A (2014) 731-737.

DOI: 10.1007/s11661-013-2027-x

[7] K. Milicka, F. Dobes, Small punch testing of P91 steel, Intl. J. Press. Vessels Pip. 83 (2006) 625-634.

[8] M.L. Saucedo-Munoz, S. Komazaki, T. Takahashi, T. Hashida, T. Shoji, Creep property measurement of service exposed SUS 316 austenitic stainless steel by the small punch creep testing technique, J. Mater. Res. 17 (2002) 1945-(1953).

DOI: 10.1557/jmr.2002.0288
