Cutting Performance in Machining of Large-Sized Spiral Bevel Gears Using Multi-Axis Control and Multi-Tasking Machine Tool

Abstract:

Large-sized spiral bevel gears are usually manufactured based on a cyclo-palloid system and have equi-depth teeth as well as a face hobbing system by a continuous cutting procedure using a special generator. It has been possible to machine the complicated shape because of the development of a multi-axis control and multi-tasking machine tool.The manufacturing method of the gears has been proposed using this development process. In this method, the spiral bevel gears are modeled based on a CAD system and are machined based on a CAM system. In this paper, the cutting performance in machining of the large-sized spiral bevel gears using the multi-axis control and multi-tasking machine toolis investigated. As a result, the relationship between the tool life of end mill and gear accuracy were made clear. The surface roughness and tool mark of the machined gears were compared with those using the special generator.

• Periodical: Applied Mechanics and Materials (Volume 595)
• Pages: 91-97
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.595.91
• Online since: July 2014
• Authors: Kazumasa Kawasaki*, Isamu Tsuji
• Keywords: Cutting Performance, End Mill, Gear Accuracy, Multi-Axis Control Andmulti-Tasking Machine Tool, Spiral Bevel Gears, Surface Roughness (SR), Tool Life, Tool Mark

References

[1] D. P. Townsend: Dudley's Gear Handbook. 2nd Ed., the Design, Manufacture, and Application of Gears, McGraw-Hill, New York, (1991), p.20. 42-20. 45.

[2] H. J. Stadtfeld: Handbook of Bevel and Hypoid Gears, Calculation, Manufacturing and Optimization, Rochester Institute of Technology, R･I･T., (1993), pp.9-12.

[3] T. Moriwaki: Multi-functional Machine Tool, Annals of CIRP, Vol. 57, No. 2, (2008), pp.736-749.

DOI: 10.1016/j.cirp.2008.09.004

[4] K. Kawasaki, I. Tsuji, H. Gunbara: Manufacturing Method of Large-Sized Spiral Bevel Gears in Cyclo-Palloid System Using Multi-Axis Control and Multi-Tasking Machine Tool, Proc. of International Conference on Gears, Garching, Germany, (2010).

DOI: 10.4028/www.scientific.net/amm.595.91

[5] F. L. Litvin and A. Fuentes: Gear Geometry and Applied Theory. 2nd Ed., Cambridge University Press, UK, (2004), pp.98-101.

[6] K. Kawasaki and I. Tsuji: Analytical and Experimental Tooth Contact Pattern of Large-Sized Spiral Bevel Gears in Cyclo-Palloid System, ASME Journal of Mechanical Design, Vol. 132, Issue 4, (2010), 041004-1-8.

DOI: 10.1115/1.4001348
