The Design and Manufacture of the Wireless Power Transmission System in the Cardiac Pacemaker

Abstract:

Generally the cardiac pacemaker is supplied power by micro battery, but the battery lifetime is limited, the Wireless Power Transmission (WPT) technology is a new method to supply power source for the cardiac pacemaker. Firstly the structure of the WPT system in the cardiac pacemaker were introduced. Then, Coupling transformer and rectifying and regulating circuit were designed. Finally, the test system of the WPT in the cardiac pacemaker was established, and the resonance frequency was 596 kHz, When the work frequencywas equal to the resonance frequency, the output power was maximal; when the input voltage of the primary winding was 5.8V, the voltage of the cardiac pacemaker may be up to 8.8V, which could effectively drive the cardiac pacemaker Record S, the results show the design is feasible.

• Periodical: Applied Mechanics and Materials (Volume 596)
• Pages: 100-103
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.596.100
• Online since: July 2014
• Authors: Xiu Quan Liu*, Yan Hong Li, Li Min, Huang Ping
• Keywords: Cardiac Pacemaker, Coupling, Wireless Power Transmission

References

[1] Appleyard M, Fireman Z, GlukHovsky A, et al. Gastroenterology, 119(2000), pp.1431-8.

[2] Lewis B, Swain P. Gastrointestinal Endoscopy, 53(2001), p. AB70.

[3] Zhou Yu, Yu Xinjie, Cheng Jinmin, Wang Chonghui, Wang Lin. TRANSACTIONS OF CHINA ELECTROTECHNICAL SOCIETY, . 25 (2010), pp.48-53 in Chinese.

[4] Baxi, V. J, Hariz, A. J. Proc. of SPIE, 6415(2006), pp.1-9.

[5] ] LIU Xiu-quan, ZHANG Wei, WU Yan-hua, HUANG Ping. Journal of System Simulation, 20 (2008), pp.2215-2219 in Chinese.

[6] Xue kaifeng. Study and Application on Multi-dimensional Wireless Power Transmission Technology for MEMS, edtied by School of Mechanical and Automotive Engineering, South China University of Technology, Guangzhou(2011) in Chinese.
