Motion Simulation and Finite Element Analysis of the Manipulator Based on SolidWorks

Abstract:

It will use SolidWorks to design structure of Manipulator and to establish the Three-dimensional Modeling based on automated welding robot of Shanghai Bamac Electric Technology Co., Ltd.,then by using the plug of simulation and motion of SolidWorks, it will focus on the Motion Simulation and Finite Element Analysis of the Manipulator. Finally the trajectory and the work space of the Manipulate can be received, and provide a basis of manipulator analysis in order to optimize the manipulator for the company.

• Periodical: Applied Mechanics and Materials (Volume 596)
• Pages: 640-645
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.596.640
• Online since: July 2014
• Authors: Peng Lu, Dao Lai Cheng, Gang Shi, Zhi Hao Zhou, Nan Kun Li
• Keywords: Manipulator, Motion Simulation, SolidWorks, Three-Dimensional Modeling

References

[1] ZHANG Jin-xi. SolidWorks and COSMOSMotion Mechanical simulation technology [M]. BEI Jing：Tsinghua University Press，(2007).

[2] ZHANG Che. Dynamics of mechanic [M]. BEI Jing：Higher Education Press, (2008).

[3] GUO Xiao-ning. Based on SolidWorks entities on both sides of the plane body motion analysis.
