Design of Active Filter Based on the Active Power Balance

Abstract:

In order to eliminate harmonics generated by the power electronic devices, from a functional point of view the amount of the balance, the use of filters to supply current and DC voltage is sampled in a controlled manner to achieve harmonic compensation, the establishment of a single-phase active power filter the control system of the model and the theoretical analysis of the program by Saber simulation software has been validated in simulation, based on a prototype developed, according to the single-phase shunt active filter to achieve our scheme can effectively harmonic compensation for pollution caused by the rectifier with inductive load, simulation and experimental results show that this method can be controlled harmonic distortion at 5.8%.

• Periodical: Applied Mechanics and Materials (Volume 596)
• Pages: 709-712
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.596.709
• Online since: July 2014
• Authors: Ling Ji*
• Keywords: Active Filters, Active Power Balance, Saber

References

[1] Zhao Liangbing, Ma Weixin, ChenJianye. Power System Technology, 1995, 19 (3): 64 ~ 67. In China.

[2] Wang Zhaoan, Yang Jun, Liu Jinjun harmonic suppression and reactive power compensation [M] Beijing: Mechanical Industry Press, 1998 (9) . 231 ~ 232. In China.

[3] Wu JC, H L-Jou Simplified Control Method for the Single-phase Active Power Filter [J] IEE Proc-Electr. Power Appl 1996, 143 (3):. 219 ~ 224.

DOI: 10.1049/ip-epa:19960120

[4] Chu Q X, Wang H. Microwave Theory and Techniques, IEEE Transactions on, 2008, 56(2): 431-439.
