Finite Element Analysis and Experimental Research for Horizontal Tank to Internal Magnetic Flux Leakage Detection

Abstract:

In view of the petroleum and petrochemical characteristics of horizontal tank, ANSYS software of finite element analysis was carried out on the horizontal tank within the magnetic flux leakage testing, analyzes the influencing factors of defect magnetic flux leakage signals. Experiments verify the finite element analysis results, the experimental results show that the research of horizontal tank within the magnetic flux leakage detection effect is obvious.

• Periodical: Applied Mechanics and Materials (Volumes 599-601)
• Pages: 321-325
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.599-601.321
• Online since: August 2014
• Authors: Li Qiang Sun*, Hong Bo Zhu, Ming Xie, Ji Xia Li
• Keywords: Experimental Study, Finite Element, Horizontal Tank, MFL

References

[1] Liu Zhiping. Based on the finite element analysis of tank bottom plate magnetic testing and evaluation method research[D]. Hubei, Huazhong university of science and technology, 2003: 24.

[2] Dai Guang, Yang Zhijun, Gao Tingyan. Based on the three dimensional finite element heat exchange tube defect leakage magnetic field numerical simulation [J]. Journal of pressure vessels. 2009, 26 (11): 21-26.

[3] Zhang Guoguang. Tank in magnetic flux leakage testing of the relationship between magnetic flux leakage signals and defect characteristics of study[J]. Journal of measurement and instrument, 2008, 35 (2): 39 ~ 41.

[4] Xiong Changsheng, He Renyang, Chen huawei, etc. Crawl the outer wall of steel pipeline magnetic flux leakage testing technology in the application of engineering [J]. Journal of pipeline technology and equipment, 2010, 26 (1): 95-98.
