Research on Technical Conditions Testing Line of Certain Tank Gun Weapon System

Abstract:

In certain tank gun technical conditions integrated testing line, we firstly realize on line test of tank gun under non disassembly situation by using data acquisition card ----4472B produced in American NI Company. It realizes multiple data concurrent acquisition and processing and ensures the integral correlation of each testing data. The system adopts PXI main control platform and actualizes the technical conditions integrated test system of breechblock and recoil system based on Virtual Instrument technology. Through practical use, the result proves that the system has prominent character of integrated testing, online testing, visual data and convenient operation.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 1630-1633
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.1630
• Online since: August 2014
• Authors: Zhen Hui Xu*, Li Xu, Shi Hai Zhou, Zhen Jun Yang
• Keywords: Breechblock Assembly, Non Disassembly Test, Recoil Mechanism, Technical Conditions, Testing Line

References

[1] Yang yanjun, The research and design of traditional weapon detected based on virtual instrument system[J]. Hebei University of Technology, 2006, 10-40.

[2] Qin shuren， Tangbaoping. Intelligent virtual controls—the Measuring instrument from whole to part[J]. The Chinese journal of mechanical engineering. 2002, 15(2).

[3] Qingsong Yang. Model-based and Data Driven Fault Diagnosis Methods with Applications to Process Monitoring[D]. Case Western Reserve University(Ph.D. ). (2004).

[4] National Instruments . The Measurement and Automation Catalog 2004[J]，(2004).

[5] Ciancarlo Forlino，Libero Nigro. Development of virtual data acquisition systems based on multimedia internet working[J]. Computer Standards&Interface. 1999，（21）.

[6] Chen Dong, Yue Lin. Development of virtual testing instrument based on LabVIEW and DAQ─PCI-4472[J]. China Measurement Technology, 2005, 31(3), 118-120.
