The Design of Magnetic Levitation Showcase for Small Commodities

Abstract:

This paper combines the maglev concept and commodity display. The commodity and the permanent magnet are hanged together and put under electromagnet, the distance from permanent magnet to magnet detected by Holzer components, and then the magnet position signal is amplified and formed a strong negative feedback control loop which can control the current of solenoid coil, at last we can hang on the different weight goods through changing the size of the electromagnet attraction.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 2549-2552
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.2549
• Online since: August 2014
• Authors: Hai Qin Feng*
• Keywords: Holl Component, Magnetic Levitation, Operational Amplifier

References

[1] Liao Bin, Yang Qin, Lu Mao. The Research of Human Factor Failure Probability Prediction Model Based on CREAM. Journal of Safety Science and Technology, 8(7), pp.46-50, (2012).

[2] Liao Bin. Ergonomics Teaching Reform Exploration and Practice. Journal of Safety Science and Technology, 9(8), pp.95-98, (2013).

[3] YANG Yan-ning, LIU L-i jun, ZHANG Zh-i yong. Circuit Design of Dot-Matrix Chinese Characters Display Based on Proteus in MCU. Chinese Journal of Liquid Crystals and Displays, 24(2) , pp.98-101, (2009).

[4] SHI Chang-hua, ZHOU Jie. Proteus-based Design and Simulation of Chinese Character Dot-matrix in SCM. Journal of Jingdezhen Comprehensive College., 22(12) , pp.1-3, (2007).

[5] HUANG Yong－jing, JIANG Xin－bin, LIU Hong1. Design of LED Dot－matrix Dynamic Display System Based on AT89C51. Journal of Chengdu Textile College, 30(7) , pp.4-6, (2013).

[6] QIAO Wei, WANG Xiao-li. Design of Intelligent LED Dot-Matrix Display Screen System. RESEARCH AND EXPLORAT ION IN LABORATORY, 29(2), pp.37-39, (2010).
