Implementation of Camera Calibration Method Based on OpenCV

Abstract:

Aimed at the applications of technology of camera calibration to 3D reconstruction, the ideal camera model is discussed, especially on the influences and solving methods of lens radial distortion andtangential distortion, and an arithmetic of camera calibration based on OpenCV (open source computer vision library) in Visual C++ environment is given. This arithmetic makes use of the functions of the library effectively, so it has high calibration precision and good robust. It can meet the needs of august reality and othercomputer vision systems.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 3796-3799
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.3796
• Online since: August 2014
• Authors: Ling Zhang*, Mu Yi Yin, Wei Li, Hai Lin Liu
• Keywords: Camera Calibration, Computer Vision, Lens Distortion, OpenCV

References

[1] Tsai R Y．A versatile camera calibration technique for high-accuracy 3D machine vision metrology using off-the-shelf TV cameras and lenses[J]．IEEE Journal of Robotics and Automation，1987，3(4)：323—344.

DOI: 10.1109/jra.1987.1087109

[2] Zhang Zhengyou．Flexible camera calibration by viewing a plane from unknown orientations[C]∥International Conference on Computer Visbn(1CCV)．Proceedings Seventh International Conference on Computer Vision．Liege，Belgium：Elsevier Science Publishers，1999：666-674.

DOI: 10.1109/iccv.1999.791289

[3] Chen Shengyong, Liu Sheng. Implementation of Computer Vision Technology Based on OpenCV [M]. Beijing: Science Press, May, (2008).

[4] Jean-Yves Bouguet. Camera calibration toolbox for Matlab [OBIOL]. 2012. http: /www. vision. caltech. edu/Bouguetj/calib_doc.

[5] David A. Forsyth, Jean Ponce. Computer Vision : A Modern Approach [M]. Person Education, Inc. (2004).
