Finite Element Analysis and Parameter Optimization for Mirror EDM without Mixed-Powder

Abstract:

By analytical and finite element analysis method, this paper analyzes the various factors on the impact of EDM surface roughness. Put forward in the process of EDM according to the coarse, medium and fine, step by step to change the order of the processing conditions, and in turn increase the momentum of the swinging electrode EDM mirror machining method. Analysis and calculate the feeding and machining allowance of each process conditions. Experiments show that in the mixed powder fluid, not replace the electrodes and processed work pieces of 45 # steel, surface roughness of work piece reached Ra0.02μm.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 629-632
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.629
• Online since: August 2014
• Authors: Xiu Wu Sui*, Bo Xue Fan, Duo Zhou, Guan Ping Liu, Teng Hu
• Keywords: ANSYS, Electric Parameter, Electrical Discharge Machining (EDM), Mirror Machining

References

[1] Wu duanyang, Zhang zongcai. Application of Mixed-Powder EDM Machining in Mold Cavity. Mould manufacture, 8: 74-77(2010).

[2] Wu junjie, Gu an, Lu chuanwei. Research on Powder-mixed Electrochemical Discharge Machining Process. Electromachining and Mould, 5: 64-66(2012).

[3] Hu bin, Li jibin. Design and Exploring of New Disposal Equipment and Process for EDM Using Powder- mixed Dielectric. Aviation Industry Press, 5: 23-26(2006).

[4] BLESY, J. P. KRUTHB. LANWERS. Sensing and Pensation of tool wear in milling EDM. Journal of Materials Processing Technology, 149(6): 139-146(2004).

[5] T. Ikai, K. Hashigushi. Heat Input for Crater Formation in EDM. Proceedings of International symposium for Electro-maching. Lausanne, Switzerland, 163-170(1995).
