Simulation Modeling and Analysis of Hydraulic Steering System with Flow Amplification Based on AMESim

Abstract:

Simulation model of Hydraulic steering system with flow amplification, which is widely used in traffic engineering machinery, is established in AMESim8.0.0 environment. Through the structure analysis of the system's three compositions, which are priority valve, steering gear and steering cylinder, are modeled by using the library of HCD. According to parameters of the actual structure of the system, the simulation parameters are set to every component of the model. Under the circumstances of step signal with different angle, rotation, and load force, the simulation results of the model turn out to be in accordance with the characteristic of the real system, which indicates feasibility and reliability of the model to specific performance analysis and optimization design.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 713-718
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.713
• Online since: August 2014
• Authors: Qian Qian Lu*, Wei Shao, Jian Hua Wei
• Keywords: AMESim8.0.0, Flow Amplification, Full Hydraulic Steering System, Simulation

References

[1] Wu Jifei, Li Furong. Technical Level Contrast of Large Displacement Hydraulic Steering Units at Home and Abroad[J]. Construction Machinery & Maintenance, 2001 (1): 28-30. (In Chinese).

[2] Tian Jinyao, Jia Huixing. Analyzing performance of flow amplifier in construction machinery with hydro-steering[J], Chinese Journal of Construction Machinery. 2006, 4(1): 43-46. (In Chinese).

[3] Ming Renxiong. Hydraulic power steering system with Load sensing and flow amplification[J]. Construction Machinery, 1999(1): 26-28. (In Chinese).

[4] Yu Youguan, Gong Guofang, Hu Guoliang. Simulation technique of AMESim and its application in hydraulic system[J]. Hydraulic and pneumatic seals, 2005(3): 28-31(In Chinese).

[5] Qin Jiasheng, You Shanlan. Features of AMESim software and its application[J]. Construction Machinery and Equipment, 2004(12): 6-8. (In Chinese).

[6] Su Donghai, Yu Jianghua. New hydraulic simulation technology of AMESim and its application[J]. Machinery. 2006, 33(11): 35-37. (In Chinese).

[7] Guo Pengyan, Xia Bin, Shi Boqiang, et al. Simulation Analysis of Hydraulic Steering System for FW-6 Underground Multi-functional Service Truck[J]. Coal Mine Machinery, 2010, 31(12): 34-37. (In Chinese).

[8] Lin Zhiyong, Jin Qing. Modeling and Simulation Analysis of Hydraulic Steering Dynamics Characteristic[J]. Hoisting and Conveying Machinery, 2006, 12: 62-65. (In Chinese).

[9] Gao Xiang, Zhao Jincai, Wang Ruoping, et al. Simulation Analysis on Hydraulic Power Assited Steering System[J]. Journal of Jiangsu University(Natural Science Edition), 2003, 24(6): 34-36. (In Chinese).

[10] Wang Xing. Research on Modeling and Simulation of Hydraulic Control Unit[J]. Journal of Nanjing Institute of Industry Technology, 2006, 6(2): 14-17. (In Chinese).
