Springback-Free Sheet Metal Structural Part Design by Topography Optimization

Abstract:

Topographgy optimization is a special kind of size optimization and it has been widely used to enhance the stiffness of sheet metal formed component by adding beads to the geometry. In this paper we present a methodology on how this concept can be employed in order to reduce formed part geometry deviation due to springback. An automotive part from Numisheet benchmark 2008 was used in this study. Several bead patterns were first generated by topography optimization subject to load constraints. Then the effects of these bead patterns location and size were studied by numerical forming and springback simulation. Our results show that the bead patterns have a significant effect on the springback. Finally, a methodology has been developed so that springback-free design can be incorporated in the early stage of part design.

• Periodical: Applied Mechanics and Materials (Volume 606)
• Pages: 171-175
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.606.171
• Online since: August 2014
• Authors: M.S. Adzman, A. Zakaria*
• Keywords: High Strength Steel (HSS), Sheet Metal Forming, Springback, Topography Optimization

References

[1] N.A. Kamal Bashah et al., Multi-regression Modeling for Springback Effect on Automotive body in White Stamped Parts, Materials and Design, Vol 23 (2013) , 175-190.

DOI: 10.1016/j.matdes.2012.10.006

[2] T. Yoshida, A. Uenishi, E. Isogai, K. Sato, S. Yonemura, Material Modeling for Accuracy Improvement of the Springback Prediction of High Strength Steel Sheets, Nippon Steel Technical Report No. 103 Jan (2013) 63-69.

[3] A. Behrouzi, B.M. Daraiani, M. Shakeri, Die Shape Design in Channel Forming Process by Compensation of Springback Error, Int. J Advanced Design and Manufacturing Technology , Vol. 3 No. 2 (2010) 17-26.

[4] T. Buranathiti, J. Cao, An Effective Analytical Model for Springback Prediction in Straight Flanging Processes, Int. J. Materials and Product Technology, Vol. 41 No 1/2/3/(2004) 137-153.

DOI: 10.1504/ijmpt.2004.004748

[5] X.K. Zhang, G.J. Zheng, J.N. Hu, C.G. Li, P. Hu, Compensation Factor Method for Modeling Springback of Auto Part Constructed from High Strength Steels, Int. J. Automotive Technology, Vol. 11, Issue 5 (2010) 721-727.

DOI: 10.1007/s12239-010-0085-2

[6] Uemori T., Sumikawas S., and Yoshida F., Modeling of Bauschinger Effect During Stress Reversal, Steel Research International, Vol 84(12) (2013).

DOI: 10.1002/srin.201300048

[7] Hu J., et al., An Automatic Spring-back Compensation Method in Die Design based on Genetic Algorithm, Met. Mater. Int., Vol. 17 no 3 (2011), 527-533.

DOI: 10.1007/s12540-011-0636-8

[8] M.P. Bendsoe and O. Sigmund , Topology Optimization Theory, Methods and Applications, second ed., Springer, Verlag Berlin Heidelberg , (2003).

[9] Manufacturing Solutions 12. 0 User's Guide HyperForm, Altair Engineering.
