Study of Adaptive Network Transmission Protocol in Mine

Abstract:

Combined with the transmission characteristics of multi node under master-slave mode, the paper design a high speed parallel transmission network based on RS485 bus, realize sampling nodes on the bus communication data packet detection using the ring buffer technique, and use the hardware timer and system parameters in the controller, combine with a custom packet to complete point to point protocol design of broadcast communication, in order to realize the free cutting of the whole system and reliable control and stable data transmission and node. The actual field test that communication rate has no error and error operation under the condition of the cable length of 2 Mbps and 100 m.

• Periodical: Applied Mechanics and Materials (Volumes 608-609)
• Pages: 435-439
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.608-609.435
• Online since: October 2014
• Authors: Xiao Lei Wu*
• Keywords: Adaptive, Custom Packet, Data Communication, RS485

References

[1] Analog Devices. Signal and Power Isolated RS 485 Transceiver with kV ESD Protection[J]. USA: Analog ± 15 Devices, (2009).

[2] Zhu Xiaochao, Xu Xuechun. Simulation and implementation of Modbus protocol based on the communication between PC and microcontroller[J]. Instrument technique and sensor, 2011; 6: 65-68.

[3] Li Huiyin. Study on data transmission system of logging cable based on USB interface[J]. Beijing: China University of Petroleum, (2006).

[4] Feng Li, Dong Guimei, Lin y ch. Short distance wireless communication technology and its application [J]. instrument technique and sensor. 2007 in the instrument of communication (10). 31-32.
