Design of Double-Disc Friction and Electromagnetic Hybrid Brake System of Passenger Car

Abstract:

The electromagnetic brake has already been acknowledged by users as one kind of contactless brake. In this paper, the basic principle and application of electromagnetic braking technology were briefly introduced first. Then the structure of the innovative hybrid brake with double disc was put forward. It employed an electromagnetic braking to reduce brake pad wear and braking system thermal recession. Based on the design requirements, the friction brake and the electromagnetic brake were designed respectively. Finally, in order to verify that whether the designed hybrid brake meets the design requirements, a bench test was carried out. The electromagnetic braking torque characteristic was tested. The results showed that the electromagnetic braking torque could approach 198N·m.Thus the design method is feasible..

• Periodical: Applied Mechanics and Materials (Volume 610)
• Pages: 156-163
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.610.156
• Online since: August 2014
• Authors: Ren He*, Xiao Dan Gu, Jun Shi
• Keywords: Electromagnetic Brake, Friction Brake, Hybrid Brake, Vehicle Engineering

References

[1] HE Ren. Review of auxiliary braking technologies of commercial automobile (in English) [J]. Journal of Traffic and Transportation Engineering. 2009, (2): 50-59.

[2] National Standard of the People's Republic of China. Safety specifications for power-driven vehicles operating on roads. GB7258-(2012).

[3] Sebastien Emmanuel, Gay, Mehradad. Integration of eddy current and friction brakes in conventional and hybrid vehicles [C]. SAE paper: 2005-01-3455.

DOI: 10.4271/2005-01-3455

[4] Jeonghoon Song. Performance evaluation of a hybrid electric brake system with a sliding mode controller [J]. Mechatronics, 2005, 15(3): 339-358.

DOI: 10.1016/j.mechatronics.2004.09.005

[5] Sebastien E. Gay, Contactless magnetic brake for automotive applications [D]. Texas A&M University, (2005).

[6] HE Ren. Wheel electromagnetic retarder and its control method of passenger cars [P]. Chinese Patent ZL200910030014. 7.

[7] DING Fu-sheng. Study on design method of wheel retarder of car [D]. Jiangsu University, (2008).

[8] YU Zhi-sheng. Automobile Theory. Beijing: China Machine Press, 2009. 3: 203-231.

[9] R. Limpert. Brake Design and Safety. Warrendale, PA: Society of Automotive Engineers, (1999).

[10] YI Feng-yan. Study on design theory and evaluation method of eddy current retarder and in automobile [D]. Jiangsu University, (2005).

[11] J.D. Edwards, B.V. Jayawant. Permanent-magnet linear eddy-current brake with a nonmagnetic reaction plate [J]. IEE Proc. -Electr. Power Apply, 1999, 146(6): 627-631.

DOI: 10.1049/ip-epa:19990574
