Mechanisms for Small and Micro Robotic Devices

Abstract:

The paper deals with problems of designing and evaluation of compliant mechanisms for small and micro robotic devices. These kinematic mechanisms are usually made from a piece of elastic material in case of positioning systems, or, create the flexural body for multi-component sensing devices. The compliance characteristics mechanical segments: joints, arms, are discussed and the procedure for evaluation / comparing characteristics of particular segments, as well as whole elastic structures is proposed. It is briefly discussed that mechanisms for this kind of devices should integrate functional features of positioning and sensing systems. The concept of the x – y micro positioning mechanisms with two-component force sensing capability is presented as an illustrative example.

• Periodical: Applied Mechanics and Materials (Volume 613)
• Pages: 11-20
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.613.11
• Online since: August 2014
• Authors: Štefan Havlík*, Jaroslav Hricko
• Keywords: Compliant Mechanism, Elastic Structure, Micro Robot, Sensor, Stiffness / Compliance Matrix

References

[1] S. Awtar, A. H. Slocum, Design of parallel kinematic x-y flexure mechanisms, in: Proc. of IDETC/CIE 2005, ASME 2005 Int. Design Engineering Technical Conferences. Computers and Information in Engineering Conference, Sept. 24-28, 2005, Long Beach, California, USA, p.89.

DOI: 10.1115/detc2005-85413

[2] Š. Havlík, G. Carbone, Design of compliant Robotic Micro-Devices, in: Proc. 15th Int. Workshop on Robobics in Alpe-Adria-Danube Region, RAAD 2006, June 15 – 17, 2006, Balatonfured, Hungary, ISBN: 963-7154-48-5.

DOI: 10.1109/raad.2010.5524556

[3] Š. Havlik: Analysis and modeling flexible robotic (micro) mechanisms. In: Proceedings of the 11th World Congress in Mechanism and Machine Science. Tianjin, April 1-4, 2004, Vol. 3,. China, pp.1390-1395.

[4] Š. Havlík.: Modeling, analysis and optimal design of multi-component force/displacement sensors. Proc. on the First ECPD Int. Conf. on Advanced Robotics and Intelligent Automation. Sept. 6-8, 1995, Athens, Greece. pp.283-289.

[5] L. L. Howell, Compliant Mechanisms, John Wiley & Sons, 2001, ISBN 047138478X.

[6] J. Hricko, Modeling Compliant Mechanisms – Comparison of Models in MATLAB / Sim-Mechanics vs. FEM, in: 21th Int. Workshop on Robotics in Alpe-Adria-Danube Region, Napoli, Italy, 2012, ISBN 978-88-95430-45-4, pp.57-62.

DOI: 10.1109/raad.2010.5524554

[7] B. H. Kang. et al. Analysis and design of parallel mechanisms with flexure joints, in Proc. of IEEE, Int. Conf. on Robotics and Automation, 2004, p.4097–4102.

[8] Lobontiu, N, Garcia, E: Two-axis flexure hinges with axially-collocated and symmetric notches,. Computers and Structures 81 (2003) 1329–1341.

DOI: 10.1016/s0045-7949(03)00056-7

[9] N. Lobontiu, Compliant Mechanisms: Design of Flexure Hinges, CRC Press, 2003, ISBN 0849313678.

[10] Mohd Nashrul Mohd Zubir, Bijan Shirinzadeh. Development of a high precision flexure-based microgripper. Precision Engineering 33 (2009) 362–370.

DOI: 10.1016/j.precisioneng.2008.10.003

[11] T. -F., Niaritsiry N. Fazenda, and R. Clavel, Study of the sources of inaccuracy of a 3DOF flexure hinge-based parallel manipulator. Proc. of IEEE Int. Conf. on Robotics and Automation, 2004, p.4091–4096.

DOI: 10.1109/robot.2004.1308911

[12] P. R. Ouyang et al. Micro-motion devices technology: The state of arts review. Int J Adv. Manuf. Technology, 2008. 38, p.463–478.

DOI: 10.1007/s00170-007-1109-6

[13] Qiaokang Liang1, et al. Design and Analysis of a Novel Six-Component F/T Sensor based on CPM for Passive Compliant Assembly. Measurement Science Review, Volume 13, No. 5, (2013).

DOI: 10.2478/msr-2013-0038

[14] J. Rausch and R. Werthschutzky. A miniature piezoresistive multi-component force sensor for minimally invasive sugery. Proc. Sensor 2009, Vol. 1. A3. 3.

DOI: 10.5162/sensor09/v1/a3.3

[15] T.S. Smith, Flexures: elements of elastic mechanisms, Gordon and Breach Science Publ., 2000, ISBN 90-5699-261-9.

[16] S. Venanzi, P. Giesen and V. Parenti-Castelli. A novel technique for position analysis of planar compliant mechanisms. Mechanism and Machine Theory (2005).

DOI: 10.1016/j.mechmachtheory.2005.01.009

[17] K. Y. Yong, T-F. Lu, D.C. Handley, Review of circular flexure hinge design equations and derivation of empirical formulations, Precision Engineering 2008, (32), ISSN 0141-6359, p.63–70.

DOI: 10.1016/j.precisioneng.2007.05.002

[18] Y. K. Yong, T-Fu Lu. Kinetostatic modeling of 3-RRR compliant micro-motion stages with flexure hinges. Mechanism and Machine Theory 44 (2009) 1156–1175.

DOI: 10.1016/j.mechmachtheory.2008.09.005

[19] www. dlr. de/rm/en/desktopdefault. aspx/tabid-3806/6231.
