A High Precision and Convenient Method to Analyze the Mechanics of Scissor Lift Platform under the Action of Combined Loads

Abstract:

Scissor lift platform had lots of kinematic pairs and the mechanics relations between them were complex. So mechanics analysis became the focus by researchers. The mechanical model of scissor lift platform under the action of combined loads was built in the paper. The calculation formula of nodal force of scissor transmission unit was given used the transfer matrix method. The calculation formulas of drive units were given on the virtual work principle. Also the calculation method of nodal forces of drive units was given. How the different distributions of drive unit influence on the nodal force was analyzed. The drive units’s position optimization method was given in this paper. In order to verify the reliability of this calculation method, an calculation example of typical structure was given. The calculation results given by the method in this paper was identical with the result given by finite element method. The conclusions obtained could serve as theoretical guidance and reference for mechanical analysis and optimal design of scissor transmission mechanism.

• Periodical: Applied Mechanics and Materials (Volume 618)
• Pages: 503-508
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.618.503
• Online since: August 2014
• Authors: Fei Peng Qu, Yuan Xue*
• Keywords: Drive Unit, Nodal Forces, Scissor Lift Platform, Transfer Matrix, Transmission Unit

References

[1] Hou Bo, He Yin-chao. High Efficiency and Low Energy Consumption Scissor Lifting Design Studies, Hydraulic and Pneumatic, 2012(1): 39-40.

[2] Xu Jun, Li Gang yan, Yang Fei. Scissor Lifting Mechanism Analysis and Optimization, Mechanical Science and Technology, 2013(6) : 25-27.

[3] Deng Hong guang, Sun Da gang, You Sikun. Scissor Lifting Plat form and Key Parameters Modeling Study, Wang Hai bin, Electrical Engineering Technology2005(7) : 20-22.

[4] Sun Guang xu, Yuan Duan cai. Hydraulic Scissor Lifting Platform dynamics System Simulation, 2010(11) : 20-22.

[5] Xie Benming, GuoYue. Scissors Hydraulic platform Finite Element Analysis, Civil Aviation University of China, 2007(2): 25-27.

[6] Zheng Yu-qiao, Zhang Dui xue, Mao Jian jun, Scissor Lifting Platform Hydraulic Cylinder Position Optimization Design, Machine Tool & Hydraulics, 2010(20) : 39-41.

[7] Zhang Fan, XUE Yuan, Chen Jin. Mechanical Analysis of Scissor Transmission Mechanism Considering (C). Applied Mechanics and Materials Vol. 419 (2013)：74-80.

DOI: 10.4028/www.scientific.net/amm.419.74
