Stress Distribution of Wellbore under Non-Uniform In Situ Stress

Abstract:

The distribution of the non-uniform in situ stress around wellbore will impair the stability of the rock of wellbore wall. Drilling the underbalanced wells and depleted formations, the instability of the wellbore can result in the drilling failure. Mechanics model of the wellbore wall rock is developed. According to the relationship between the stress function and components of stresses, the superposition principle is adopted to develop the formulas of the radial, hoop, and shear stresses of the wellbore wall under the non-uniform in situ stress. The formula of the mud density which do not crash the rock of wellbore wall is derived. The error of the mud density between fitting formula developed in the paper and theoretical method is less than 2.5%. The mud density that ensure the stability of wellbore is determined.

• Periodical: Applied Mechanics and Materials (Volumes 633-634)
• Pages: 1311-1314
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.633-634.1311
• Online since: September 2014
• Authors: Xiao Zeng Wang*, Zhan Qu, Yi Hua Dou
• Keywords: Mud Density, Non-Uniform In Situ Stress, Superposition Principle, Von Mises Stress, Wellbore Stability

References

[1] S. Hoang, Y. Abousleiman, U. Tare. SPE 90245, (2004).

[2] Daniel Moos, Julie Kowan, Thomas Finkbeiner. SPE 135894, (2010).

[3] S. Li,C. Purdy. SPE 139280, (2010).

[4] Yao Zhijun, Li Xiangrun. The northeast coal technology, Vol. 4 (1997), p.3.

[5] Li J., Liu G.H., Chen M. Journal of rock mechanics and engineering, Vol. 30 (2011), p.2481.

[6] Wang J.J., Lin K., Wang X.H. Journal of China University of Petroleum, Vol. 28 (2004), p.45.
