Elastic-Plastic Numerical Simulation of Cold Rotary Forging for Hypoid Gear and the Springback Error

Abstract:

To achieve the effect of anti-fatigue manufacturing for hypoid gear, the author put forward a new type cold rotary forging technology, the method simplifies the die structure and adopts the local line contact continuous plastic forming. Based on the basic theory of elastic-plastic finite element method (FEM),the author uses ABAQUS to carry out numerical simulation of cold rotary forging and discuss how to build finite element geometric model and grid it in detail, and analyse the definition of workpiece material model in ABAQUS and the merger technology of Abaqus / Explicit and Abaqus / Standard. In order to measure springback error accurately, the alveolar surface shap after springback was got through the technology of surface reconstruction, it was put into Geomagic Qualify software and compare with target CAD model,then the springback error can befully assessed through comparing results.The examles proof that ABAQUS can simulate the deformation and springback process accurately, springback error of cold rotary forging can not be ignored,so springback error must be compensated.

• Periodical: Applied Mechanics and Materials (Volumes 633-634)
• Pages: 826-831
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.633-634.826
• Online since: September 2014
• Authors: Yu Gong Dang, Xiao Zhong Deng*, Bin Wang
• Keywords: Anti-Fatigue Manufacturing, Cold Rotary Forging, Hypoid Gear, Numerical Simulation, Springback Error

References

[1] Yugong Dang, Xiaozhong Deng, Shaowu Nie, et al. New Schemeof Cold Rotary Forging for Hypoid Gear and Its Feasibility[J]. Journal of Bejing University of Technology, 2013. 39(9): 1290-1296.

[2] Meng Zhang, Yamin Hu. Technology of Rotary Forging[M]. Beijing: China Machine Press, (1998).

[3] Yamin Hu, Lin Hua, Zhouyi Lai, et al. The Technology of Cold Precision Orbital Forming of Various Gears in Automobile and Autobicycle[J]. China Mechanical Engineering，2006. 17 (10): 140-143.

[4] Tao Zeng. Design and Processing of Spiral bevel gear[M]. Ha Erbin: Harbin Institute of Technology Press, (1989).

[5] Hua Zhang. Theory and Experiments Research of Hypoid gear Manufacturing with Modify-roll Method on 4-axis CNC cutting Machine[D]. Zhen Jiang: Jiangsu University, (2008).

[6] Jinyuan Tang, Taiping Pu. Spiral Bevel Gear Meshing Stiffness Calculations Based on the Finite Element Method[J] . Journal of Mechanical Engineering , 2011. 6(11): 23-29.

DOI: 10.3901/jme.2011.11.023

[7] Taiping Pu. LTCA for Spiral bevel gear and Research of Meshing Stiffness Calculations Based on the Finite Element Method[D]. Chang Sha: Central south University, (2010).

DOI: 10.3901/jme.2011.11.023

[8] Xifeng Zhang. Numerical Simulation study on Cold Rolling Process of Bearing Rings[D]. JiNan: ShanDong University, (2008).
