Hammer Rod Optimization of Large Tonnage Air Hammer

Abstract:

The hammer rod of large tonnage air hammer is easily damaged during operating process. Positions on the hammer rod, which may be broken, are not determined by linear fracture mechanics. Meanwhile, it does not provide possible measures for improvement. According to the actual weight of the hammer rod, about 0-10% larger than its nominal weight, an improved design method is proposed in the paper, which does not affect the performance of the air hammer. This method effectively solves the problem of breaking hammer rods and improves their service life.

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 81-84
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.81
• Online since: September 2014
• Authors: Yin Sai Guo*, Yi Zhang, Ming Ke Cheng
• Keywords: Finite Element Numerical Analysis, Hammer Rod Optimization, Large Tonnage Air Hammer

References

[1] Cheng Li. Analysis for hammer rod fatigue macroscopic fracture of large forging hammer, J. Journal of physical and chemical inspection (physical volume), 2007, 20 (7) : 22-24.

[2] Wang Yongmei, Zhao Hong. C41-2000 air hammer design, J. Journal of mining machinery, 2009, 2 (9) : 12-13.

[3] Chen Xueming, Liu Xinlian, Zhu Yuanfang. Hammer rod fracture reason and repair, J. China equipment engineering, 1997, 18 (12) : 52-54.

[4] An Daoren. How to improve the service life of forging hammer hammer rod, J. Mechanical workers. Hot working, 1994, 66 (1) : 57 - 60.

[5] Xu Rongchang, Sun Huichao. The development of finite element simulation technology and its application, J. Science and technology in lai steel, 2008, (8) : 76-78.
