Investigation on Mechanism of Ultra-Smoothed Surface with a Micro Slot on the Flank Face in Micro Cutting

Abstract:

Micro cutting is a promising manufacturing method to obtain good surface integrity. Surface roughness shows size effect when the uncut chip thickness is smaller than the cutting edge radius. A special micro slot on the flank face of cutting tools was manufactured with discharge. Two groups of micro orthogonal cutting were conducted. The surface roughness of machined surface was measured and compared to each other. The results show that surface roughness decreases first and then increases with the ratio of uncut chip thickness to cutting edge radius. The surface machined with micro slot is better than that of without micro slot due to the micro slot restrain the back side flow of work piece based on the finite element model.

• Periodical: Applied Mechanics and Materials (Volumes 651-653)
• Pages: 764-767
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.651-653.764
• Online since: September 2014
• Authors: Tao Zhang, Hou Jun Qi, Gen Li
• Keywords: Mechanism, Micro Cutting, Micro Slot, Surface Roughness (SR)

References

[1] J. Loxham, J. Purcell: Conference Proceedings Vol. 182 (1967), pp.205-210.

[2] W. Wang, S.H. Kweon, S.H. Yang: J Mater Process Tech, Vol. 162-163 (2005), pp.702-708.

[3] K. Weinert, P. Kahnis: Proceedings of the 2nd International Conference on New Forming Technology, Bremen, (2007), pp.481-489.

[4] S. Filiz, C. M. Conley, M. B. Wasserman: Int J Mach Tool Manu Vol. 47 (2007), pp.1088-1100.

[5] Y. Zhao: Harbin: Harbin institute of technology, 2008, 53-55.

[6] A. Aramcharoen, P. T. Mativenga: Precis Eng Vol. 33(2009), pp.402-407.

[7] L. Zhang: Nanjing: Nanjing University of Aeronautics and Astronautics, 2007, 104-110.

[8] K. Liu, S. N. Melkote: Int J Mach Tool Manu Vol. 46 (2006), pp.1778-1785.

[9] T. Zhang, Z. Liu, Z. Shi, Ch. Xu: Int J Precis Eng Man Vol. 14 (2013), pp.345-349.
