An Optimized Methodology for Process Quality Analysis and Monitoring Activities in Case of Sheet Metal Bearing Cages Stamping

Abstract:

The quality of bearing cages is influenced by a variety of technological factors which depend on the material they are manufactured of, on the hydraulic press and on the punching-stamping die. The paper presents an optimized methodology introduced and developed for process quality analysis and monitoring activities involved in the stamping technology in order to manufacture roller bearing steel cages. The stamping technology presented in this case study is part of a larger industrial process of manufacturing steel window-type cages for spherical roller bearings with two rows of symmetrical rollers. This approach aims to improve a similar process quality analysis and monitoring activities which were previously developed on the basis of cause & effect analyses made upon the influence of qualitative and quantitative parameters involved in a quality and accurate stamping process.

• Periodical: Applied Mechanics and Materials (Volume 657)
• Pages: 183-187
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.657.183
• Online since: October 2014
• Authors: Marius Ionuţ Rȋpanu*, Gheorghe Nagîț, Vasile Merticaru, Marius Andrei Mihalache, Mihai Boca, Valerica Huşanu
• Keywords: Bearing Cage, Cause, Effect Analysis, Process Quality, Sheet Metal, Stamping

References

[1] NSK – Romania Corporate 2012. Require precision movement – Bearings, linear components, auto components, available from: http: /www. nsk. ro/cps/rde/xbcr/nsk_microsite/Romania-Corporate. pdf, accessed at: 15. 02. (2014).

[2] M.I. Ripanu et al., Process quality analysis and monitoring methodology for roller bearings cages stamping, Annals of the Oradea University, Fascicle of Management and Technological Engineering, 11 (2012) 4. 128 – 4. 135.

DOI: 10.15660/auofmte.2012-1.2593

[3] M.I. Ripanu, Gh. Nagit, V. Merticaru, A.M. Mihalache, I.I. Hurja, Influence of the clearances in the stamping device upon the burrs resulted on the stamped bearing cages windows, Applied Mechanics and Materials, 371 (2013) 153-158.

DOI: 10.4028/www.scientific.net/amm.371.153

[4] TIMKEN, 2012, Interactive catalog. Ball bearings catalog, available from: http: /catalog. timken. com/WebProject. asp?CodeId=7. 5. 9. 16&bookcode=tbb12#, accessed at: 23. 05. (2012).

[5] M.I. Ripanu, Theoretical and experimental researches regarding the quality and precision of stamped bearings cages, Thesis, Iasi, (2014).

[6] R. Hambli, Design of experimental based analysis for sheet metal blanking processes optimization, International Journal Advanced Manufacturing Technology, 19 (2002) 403-410.

DOI: 10.1007/s001700200041
