On the Generation of Complex Trajectories Using a Robotic System with Six Degrees of Freedom

Abstract:

In this paper a method that allows the generation of complex trajectories using a RRTRRR robotic system (with five rotation modules and a translation module) is presented. The method is based on the decoupling between the positioning function and the orientation function of the tool frame (O_Tx_Ty_Tz_T) attached to the robot gripper. The method permits to determine all the solutions corresponding to the robot coordinates that allow obtaining the movement of the tool frame with imposed position and orientation parameters. Finally, some simulation results are presented in the case when O_T is moving along a parabolic trajectory with an imposed orientation of the tool frame.

You might also be interested in these eBooks

Engineering Solutions and Technologies in Manufacturing

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 657)

Pages:

803-807

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.657.803

Citation:

Cite this paper

Online since:

October 2014

Authors:

Dorin Bădoiu, Marius Petrescu, Georgeta Toma, Johannes Cornelis Helthuis

Keywords:

Complex Trajectories, Orientation, Position, Robotic Systems, Tool Frame

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D. Bădoiu, The Mechanics of Robotic Systems (in Romanian), Petroleum-Gas University of Ploiesti Publishing House, Ploiesti, (2006).

Google Scholar

[2] R.N. Jazar, Theory of Applied Robotics: Kinematics, Dynamics and Control (Second Edition), Springer, (2010).

Google Scholar

[3] D. Bădoiu, Structural and Cinematic Analysis of the Mechanisms (in Romanian), Technical Publishing House, Bucharest, (2001).

Google Scholar

[4] J.J. Craig, Introduction to Robotics: Mechanics and Control (Third Edition), Pearson Prentice Hall, (2005).

Google Scholar

[5] Information on http: /www. festo-didactic. com accessed: 21. 03. (2014).

Google Scholar

[6] Information on http: /new. abb. com/products/robotics/robotstudio accessed: 21. 03. (2014).

Google Scholar

[7] M.B. Monagan, K.O. Geddes, K.M. Heal, G. Labahn, S.M. Vorkoetter, J. McCarron, P. DeMarco, Maple Introductory Programming Guide, Maplesoft, a division of Waterloo Maple Inc., (2005).

DOI: 10.1007/978-1-4684-0487-6

Google Scholar
