Mathematical Modeling for the Prediction of Depth of Penetration in Double Pulse GMA Welding Using Fractional Factorial Method

Abstract:

The quality of weld joint is directly influenced by the input process parameters influenced by various process parameters during welding. The weld quality can be decided by bead geometry viz., depth of penetration and bead width. Inadequate depth of penetration will lead to failure of the welded structure. This paper presents the development of mathematical model for the prediction of depth of penetration of weld bead geometry in pulsed gas metal arc welding process in double pulse mode. The model is based on experimental data .In this investigation four input process parameters wire feed rate, ratio of wire feed rate to travel speed, amplitude and double pulse frequency are considered. The experiments were conducted on 6mm thickness plate of 5083 H111 aluminum alloy using fractional factorial design of experiments. The mathematical model for depth of penetration is developed using multiple nonlinear regression. The developed model is then compared with experimental results and it is found that the results obtained from mathematical model are accurate. The obtained results help in selecting quickly the process parameters to achieve the desired quality.

• Periodical: Applied Mechanics and Materials (Volume 660)
• Pages: 347-351
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.660.347
• Online since: October 2014
• Authors: K. Manikya Kanti*, Srinivasa Rao Pedapati, Ginka Ranga Janardhana, A.M.A. Rani
• Keywords: Aluminium Alloy, Amplitude, Double Pulse Frequency, Double Pulse GMA Welding, Fractional Factorial Method, Mathematical Modeling, Regression Analysis, Travel Speed, Wire Feed Rate

References

[1] P Srinivasa Rao, O P Gupta, Murty SSN, Rao ABK, Effect of process parameters and mathematical model for the prediction of bead geometry in pulsed GMA welding, Int. J. Adv. Manuf. Technol., 45 (2009) 496-505.

DOI: 10.1007/s00170-009-1991-1

[2] I S Kim, KJ Son, YS Yang, Prasad YKDV, Sensitivity analysis for process parameters in GMA welding processes using a factorial design method. Int. J. Mach. Tools Manuf., 43 (2003)763-769.

DOI: 10.1016/s0890-6955(03)00054-3

[3] J P Ganjigatti, D K Pratihar, Choudhury AR, Modeling of the MIG welding process using statistical approaches, Int. J. Adv. Manuf. Technol., 35 (2008) 1166-1190.

DOI: 10.1007/s00170-006-0798-6

[4] P K Palani, N Murugan, Development of mathematical models for prediction of weld bead geometry in cladding by flux cored arc welding, Int. J. Adv. Manuf. Technol., 30 (2006) 669-676.

DOI: 10.1007/s00170-005-0101-2

[5] K Siva, N Murugan, R Logesh, Optimization of weld bead geometry in plasma transferred arc hard faced austenitic stainless steel plates using genetic algorithm, Int. J. Adv. Manuf. Technol., 41(2009) 24-30.

DOI: 10.1007/s00170-008-1451-3

[6] T Kannan, J Yoganandh, Effect of process parameters on clad bead geometry and its shape relationships of stainless steel claddings deposited by GMAW, Int. J. Adv. Manuf. Technol., 47 (2010) 1083-1095.

DOI: 10.1007/s00170-009-2226-1

[7] I S Kim, J S Son, C E Park, Lee CW, Prasad YKDV, A study on prediction of bead height in robotic arc welding using a neural network, J. Mater. Process Technol., 130-131 (2002) 229-234.

DOI: 10.1016/s0924-0136(02)00803-8

[8] K Manikya Kanti, P Srinivasa Rao, Prediction of bead geometry in pulsed GMA welding using back propagation neural network, J. Mater. Process Technol., 200 (2008) 300-305.

DOI: 10.1016/j.jmatprotec.2007.09.034

[9] X Zhang, A Daneryd, B Holmgren, D Skarin, Arc and weld profile predictions for zinc-coated thin steel plates, Proc. of 8th int. conf. on Trends in welding research, Georgia, USA, 2008, 339-347.

[10] K Mutombo, M D Toit, Mechanical properties of 5083 aluminum welds after manual and automatic pulsed gas metal arc welding using E5356 filler, Mater. Sci. Forum, 654 (2010) 2560-2563.

DOI: 10.4028/www.scientific.net/msf.654-656.2560

[11] D C Montgomery, Design and analysis of experiments, fifth ed., Wiley, New York, (2006).

[12] Ping Yao, JiaXiang Xue, Kang Zhou, and XiaoJunWang, Sample Entropy-Based Approach to Evaluate the Stability of Double-Wire Pulsed MIG Welding, Mathematical Problems in Engineering, 14 (2014), 1-8.

DOI: 10.1155/2014/869631
